FRONT FLOOR AIRBAG SENSOR REMOVAL

CAUTION / NOTICE / HINT

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed, installed or replaced during the front floor side airbag sensor removal/installation are shown below.

Necessary Procedures after parts removed / installed / replaced
Replacement Part or Procedure Necessary Procedures Effects / Inoperative when not Performed Link
Disconnect cable from negative battery terminal Drive the vehicle until stop and start control is permitted (approximately 5 to 60 minutes) Stop and start system

Click here

Memorize steering angle neutral point Pre-crash safety system

Click here

Tech Tips


  • Use the same procedure for the RH and LH sides.

  • The procedure listed below is for the LH side.

PROCEDURE


  1. PRECAUTION

    CAUTION:

    Be sure to read Precaution thoroughly before servicing.

    B0069A2

    Click here

    Note

    After turning the ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notice before proceeding with work.

    Click here

  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL

    CAUTION:


    • Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.

    • If the airbag deploys for any reason, it may cause a serious accident.

    B00693Q

    Note

    When disconnecting the cable, some systems need to be initialized after the cable is reconnected.

    Click here

  3. REMOVE FRONT DOOR SCUFF PLATE LH

    for Single Cab:

    Click here

    for Double Cab:

    Click here

    for Smart Cab:

    Click here

  4. REMOVE REAR DOOR SCUFF PLATE LH (for Double Cab)

    Click here

  5. REMOVE LOWER CENTER PILLAR GARNISH LH (for Double Cab)

    Click here

  6. REMOVE FRONT FLOOR SIDE AIRBAG SENSOR


    1. Check that the ignition switch is off.

    2. Check that the cable is disconnected from the negative (-) battery terminal.

      CAUTION:


      • B00693Q

        Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.

      • B0068ME

        If this procedure is performed without disconnecting the negative (-) terminal of the battery, the airbag may deploy even if an impact is applied only to the front floor side airbag sensor. Therefore, make sure that the negative (-) terminal of the battery is disconnected before performing this procedure.

    3. Disconnect the airbag connector.

      Note

      When disconnecting any airbag connector, take care not to damage the airbag wire harness.


      1. Push down the housing lock and slide the CPA. (At this time, the airbag connector cannot be disconnected yet.)

        B0028CGC19
        *a Housing Lock *b CPA
        *c CPA Upper Part - -

      2. Push down the housing lock again and disconnect the airbag connector.

        Note

        Do not push down the upper part of the CPA shown in the illustration when disconnecting the airbag connector.

    4. B006968C01
      *A for Single Cab, Smart Cab
      *B for Double Cab

      Remove the nut.

      Note

      Loosen the bolt while holding the front floor side airbag sensor because the front floor side airbag sensor guide is easily damaged.

    5. Detach the guide and remove the front floor side airbag sensor.

      Note

      If the front floor side airbag sensor has been dropped, replace it with a new one.
