TIRE PRESSURE WARNING INITIATOR DRIVER(for LHD) REMOVAL

PROCEDURE

1. REMOVE LOWER NO. 2 INSTRUMENT PANEL AIRBAG ASSEMBLY

   Click here

2. REMOVE INSTRUMENT PANEL FINISH PANEL END RH

   Click here

3. REMOVE FRONT NO. 2 CONSOLE BOX INSERT

   Click here

4. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY

   Click here

5. REMOVE TIRE PRESSURE MONITOR INITIATOR DRIVER




   1.

      Remove the nut.

   2. Disengage the hook to remove the tire pressure monitor initiator driver.

   3. Disconnect the connector from the tire pressure monitor initiator driver.
