REAR BLOWER RESISTOR (for Heater) INSPECTION


  1. INSPECT REAR HEATER BLOWER RESISTOR


    1. B007UM5E04

      Remove the rear heater blower resister and disconnect the connector.

    2. Measure the resistance according to the value(s) in the table below.

      Standard resistance
      Tester connection Condition Specified condition
      1 - 4 Always 2.59 to 2.99 Ω
      1 - 2 Always 1.38 to 1.60 Ω
      1 - 3 Always 0.36 to 0.42 Ω

      If the resistance value is not as specified, replace the rear blower resistor.
