UPPER INSTRUMENT PANEL COMPONENTS
ILLUSTRATION
| *A | for Single Cab | *B | for Smart Cab |
| *C | for Double Cab | - | - |
| *1 | COMBINATION METER ASSEMBLY | *2 | COWL SIDE TRIM BOARD LH |
| *3 | FRONT DOOR SCUFF PLATE LH | *4 | INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY |
| *5 | INSTRUMENT SIDE PANEL LH | *6 | NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY |
ILLUSTRATION
| *A | for Single Cab | *B | for Smart Cab |
| *C | for Double Cab | - | - |
| *1 | COWL SIDE TRIM BOARD RH | *2 | FRONT DOOR SCUFF PLATE RH |
| *3 | INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY | *4 | INSTRUMENT SIDE PANEL RH |
| *5 | NO. 1 INSTRUMENT PANEL BOX DOOR SUB-ASSEMBLY | *6 | NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY |
ILLUSTRATION
| *A | w/o Assist Grip | *B | w/ Assist Grip |
| *C | w/ Front Passenger Airbag | - | - |
| *1 | ASSIST GRIP SUB-ASSEMBLY | *2 | FRONT PILLAR GARNISH LH |
| *3 | FRONT PILLAR GARNISH RH | *4 | UPPER INSTRUMENT PANEL SUB-ASSEMBLY |
 |
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping" : N*m (kgf*cm, ft.*lbf) | - | - |
ILLUSTRATION
| *A | w/ Cool Box | *B | w/o Cool Box |
| *C | w/ Navigation System | - | - |
| *1 | CENTER INSTRUMENT PANEL REGISTER ASSEMBLY | *2 | DEFROSTER NOZZLE ASSEMBLY |
| *3 | NAVIGATION ANTENNA ASSEMBLY | *4 | NO. 1 HEATER TO REGISTER DUCT SUB-ASSEMBLY |
| *5 | NO. 2 HEATER TO REGISTER DUCT | *6 | NO. 2 HEATER TO REGISTER DUCT SUB-ASSEMBLY |
ILLUSTRATION
| *A | w/ Front Passenger Airbag | - | - |
| *1 | INSTRUMENT PANEL PASSENGER WITHOUT DOOR AIRBAG ASSEMBLY | *2 | METER MOUNTING BRACKET |
| *3 | NO. 1 INSTRUMENT PANEL CUSHION | *4 | NO. 2 INSTRUMENT PANEL CUSHION |
| *5 | NO. 2 INSTRUMENT PANEL WIRE | *6 | NO. 3 INSTRUMENT PANEL CUSHION |
| *7 | NO. 4 INSTRUMENT PANEL CUSHION | *8 | NO. 5 INSTRUMENT PANEL CUSHION |
| ● | Non-reusable part | - | - |
