FRONT SEATBACK HEATER INSPECTION

PROCEDURE


  1. INSPECT FRONT SEATBACK PAD WITH COVER


    1. A01O97RC02
      *a

      Component without harness connected

      (Front Seatback Pad with Cover)

      Measure the resistance according to the value(s) in the table below.

      Standard Resistance
      for Synthetic Leather Seat
      Tester Connection Condition Specified Condition
      1 - 2 Always 5.59 to 6.83 Ω
      for Leather Seat
      Tester Connection Condition Specified Condition
      1 - 2 Always 5.59 to 6.83 Ω

      If the result is not as specified, replace the front seatback pad with cover.
