ENGINE GENERAL MAINTENANCE

CAUTION / NOTICE / HINT

Tip:

Perform these procedures after the engine has cooled down.

PROCEDURE

  1. INSPECT DRIVE BELT

    1. Check the drive belt.

      Type

      See procedure

      2AR-FXE

      Click here

  2. REPLACE ENGINE OIL AND OIL FILTER

    1. Replace the engine oil and oil filter.

      Type

      See procedure

      2AR-FXE

      Click here

  3. INSPECT COOLING AND HEATER SYSTEM

    Check that the radiator and condenser are not blocked with leaves, dirt or insects, and clean them if necessary. Also check the hose connection for the installation condition, corrosion, etc.

  4. INSPECT ENGINE COOLANT

    1. Inspect the engine coolant.

      Type

      See procedure

      2AR-FXE

      Click here

  5. REPLACE ENGINE COOLANT

    1. Replace the engine coolant.

      Type

      See procedure

      2AR-FXE

      Click here

  6. INSPECT INVERTER COOLANT

    1. Inspect the inverter coolant.

      Type

      See procedure

      2AR-FXE

      Click here

  7. REPLACE INVERTER COOLANT

    1. Replace the inverter coolant.

      Type

      See procedure

      2AR-FXE

      Click here

  8. INSPECT ENGINE OIL COOLER HOSE AND CONNECTIONS (w/ Oil Cooler)

    1. Check the oil cooler assembly for cracks, leakage, loose connections and deformation.

  9. INSPECT EXHAUST PIPES AND MOUNTINGS

    1. Visually check the pipes, hangers and connections for severe corrosion, leaks or damage.

  10. REPLACE SPARK PLUGS

    1. Replace the spark plugs.

      Type

      See procedure

      2AR-FXE

      Click here

  11. INSPECT AUXILIARY BATTERY

    1. Check the auxiliary battery.

      Type

      See procedure

      2AR-FXE

      Click here

  12. REPLACE FUEL FILTER

    1. Replace the fuel filter.

      Type

      See procedure

      2AR-FXE (w/ Canister Pump Module)

      Click here

      2AR-FXE (w/o Canister Pump Module)

      Click here

  13. ADD FUEL INJECTION SYSTEM

    1. Add fuel injector cleaner to the fuel tank.

  14. INSPECT AIR CLEANER FILTER ELEMENT

    1. Remove the air cleaner filter element.

    2. A156094

      Check that the air cleaner filter element is not excessively dirty.

      If the air cleaner filter element is excessively dirty, replace the air cleaner filter element.

    3. If cleaning the air cleaner filter element, blow compressed air as shown in the illustration to clean it.

    4. Reinstall the air cleaner filter element.

  15. INSPECT FUEL TANK CAP GASKET

    1. Check the fuel tank cap gasket.

      Type

      See procedure

      2AR-FXE (w/ Canister Pump Module)

      Click here

      2AR-FXE (w/o Canister Pump Module)

      Click here

  16. INSPECT FUEL LINES, CONNECTIONS, FUEL TANK VAPOR VENT SYSTEM HOSES AND FUEL TANK BANDS

    1. Visually check the fuel lines and hoses for cracks, leaks, loose connections, or deformation.

    2. Check the tank bands for looseness or deformation.

  17. INSPECT CHARCOAL CANISTER

    1. Inspect the charcoal canister.

      Type

      See procedure

      2AR-FXE (w/ Canister Pump Module)

      Click here

      2AR-FXE (w/o Canister Pump Module)

      Click here
