TORQUE CONVERTER AND DRIVE PLATE INSPECTION

PROCEDURE


  1. INSPECT TORQUE CONVERTER ASSEMBLY


    1. Inspect the one-way clutch.


      1. A004IOVE10

        Install SST into the inner race of the one-way clutch.

        SST
        09350-32014   ( 09351-32010 )

      2. Set SST so that it fits in the notch of the torque converter hub and the outer race of the one-way clutch.

        SST
        09350-32014   ( 09351-32020 )
      3. A004H0LE13

        With the torque converter assembly standing on its side, check that the clutch locks when SST is turned counterclockwise and rotates freely and smoothly when SST is turned clockwise.

        Text in Illustration
        A004I9S Lock
        A004KUZ Free

        If the results are not as specified, clean the torque converter assembly and recheck the one-way clutch.

        If the results still are not as specified even after cleaning the torque converter assembly, replace the torque converter assembly.

    2. A004IDGE03
      Text in Illustration
      *a Sample showing maximum allowable amount of powder in ATF

      Determine the condition of the torque converter assembly.


      1. Check that the following conditions are met:


        • During the stall test or when the shift lever is in N, metallic sounds are not emitted from the torque converter assembly.

        • The one-way clutch turns in one direction and locks in the other direction.

        • The amount of powder in the ATF is not more than the sample shown in the illustration.

          If the results are not as specified, replace the torque converter assembly.

        Tech Tips

        The sample illustration shows approximately 0.025 liters (0.026 US qts, 0.022 Imp. qts) of ATF taken from a removed torque converter assembly.

    3. Replace the ATF in the torque converter assembly.


      1. If the ATF is discolored and/or has a foul odor, stir the ATF in the torque converter assembly thoroughly and drain the ATF with the torque converter assembly facing upward.

    4. Clean and check the transmission oil cooler.


      1. A004J4K

        If the torque converter assembly is inspected or the ATF is replaced, clean the transmission oil cooler.

        Tech Tips


        • Apply compressed air at 196 kPa (2.0 kgf/cm2, 28 psi) into the inlet hose.

        • If a large amount of powder is found in the ATF, add new ATF using a bucket pump and clean the transmission oil cooler and oil pipe line again.

      2. If the ATF is cloudy, inspect the transmission oil cooler.

    5. A004IYBE94
      Text in Illustration
      *a Correct
      *b Incorrect
      *c Bottom is damaged

      Prevent deformation of the torque converter assembly and damage to the oil pump gear.


      1. When any marks due to interference are found on the end of a bolt for the torque converter assembly and on the bottom of the bolt hole, replace the bolt and torque converter assembly.

      2. Make sure all of the bolts are the same length.

      3. Make sure no spring washers are missing.

  2. INSPECT DRIVE PLATE


    1. Check the drive plate for damage.

    2. A004JSF

      Set up a dial indicator and measure the runout of the 6 portions around the torque converter contact surfaces.

      Text in Illustration
      A004H2J Measuring Point
      Maximum runout
      0.30 mm (0.0118 in.)

      If the runout is more than the maximum, or the drive plate is damaged, replace the drive plate Click here.
