TILT SENSOR COMPONENTS

ILLUSTRATION

E266956C02

*1

COWL SIDE TRIM BOARD LH

*2

FRONT DOOR SCUFF PLATE LH

*3

LOWER CENTER PILLAR GARNISH LH

*4

OUTER LAP BELT ANCHOR COVER

*5

REAR DOOR SCUFF PLATE LH

*6

THEFT WARNING TILT SENSOR

*7

YAWRATE SENSOR BRACKET

*8

FRONT SEAT OUTER BELT FLOOR ANCHOR
V100146

N*m (kgf*cm, ft.*lbf): Specified torque

-

-
