AIR CONDITIONING PANEL(for Manual Air Conditioning System) COMPONENTS

ILLUSTRATION

A004J9WE01
*1 CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY
*2 NO. 2 INSTRUMENT CLUSTER FINISH PANEL GARNISH
*3 NO. 1 INSTRUMENT CLUSTER FINISH PANEL GARNISH
*4 AIR CONDITIONING CONTROL ASSEMBLY

ILLUSTRATION

A004K58E03
