CAMSHAFT POSITION SENSOR COMPONENTS
ILLUSTRATION
*1 |
CAMSHAFT POSITION SENSOR (for Intake Side) |
*2 |
CAMSHAFT POSITION SENSOR (for Exhaust Side) |
*3 |
AIR CLEANER CASE SUB-ASSEMBLY (for Intake Side) |
*4 |
OIL VAPOR RE-INDUCTION HOSE (for Intake Side) |
*5 |
HEATER HOSE (for Intake Side) |
*6 |
ENGINE COOLANT TEMPERATURE SENSOR CONNECTOR (for Intake Side) |
 |
N*m (kgf*cm, ft.*lbf): Specified torque |
- |
- |
