FRONT LOWER SUSPENSION ARM REASSEMBLY


  1. INSTALL FRONT NO.1 LOWER ARM BUSHING


    1. B007WDXE01

      Using SST and a press, press a new front No.1 lower arm bushing into the front suspension lower arm.

      SST
      09502-24010
      09726-27012   ( 09726-01031, 09726-02041 )

  2. INSTALL FRONT NO.1 SPRING BUMPER


    1. B007SYXE01

      Install front No.1 spring bumper to the front suspension lower arm with the nut.

      Torque:
      36 N*m  { 367 kgf*cm, 27 ft.*lbf }
