FRONT BLOWER MOTOR INSTALLATION

CAUTION / NOTICE / HINT

Tech Tips


  • Use the same procedure for RHD and LHD vehicles.

  • The procedure listed below is for LHD vehicles.

PROCEDURE


  1. INSTALL BLOWER WITH FAN MOTOR SUB-ASSEMBLY


    1. B0025AUC01
      B0068HS Screw
      B006964 Connector

      for Automatic Air Conditioning System, w/ Rear Resistor Duct, for LHD:


      1. Install the blower with fan motor sub-assembly with the 3 screws.

      2. Connect the 2 connectors.

      3. Attach the clamp.

    2. B0028CIC01
      B0068HS Screw
      B006964 Connector

      for Automatic Air Conditioning System, w/ Rear Resistor Duct, for RHD:


      1. Install the blower with fan motor sub-assembly with the 3 screws.

      2. Connect the connector.

      3. Attach the clamp.

    3. for Automatic Air Conditioning System, w/o Rear Resistor Duct:


      1. Install the blower with fan motor sub-assembly with the 3 screws.

      2. Connect the connector.

      3. Attach the clamp.

    4. B0024E0C01
      B0068HS Screw
      B006964 Connector

      for Manual Air Conditioning System, Manual Cooler System:


      1. Install the blower with fan motor sub-assembly with the 3 screws.

      2. Connect the connector.

      3. Attach the clamp.

  2. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY

    Click here
