NAVIGATION SYSTEM Voice Guidance does not Function

WIRING DIAGRAM

B004GQTE13
*1 Navigation ECU
*2 Radio Receiver Assembly

PROCEDURE


  1. CHECK VOICE GUIDANCE SETTING


    1. Check that the voice guidance settings are not off.

      OK
      Voice guidance settings are not off.
      Result
      Proceed to
      OK
      NG

    NG

    CHANGE VOICE GUIDANCE SETTINGS TO ON

    OK

  2. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - NAVIGATION ECU)


    1. Disconnect the O148 radio receiver assembly connector.

    2. Disconnect the O150 navigation ECU connector.

    3. Measure the resistance according to the value(s) in the table below.

      Standard Resistance
      Tester Connection Condition Specified Condition
      O148-22 (SI+) - O150-6 (VOI+) Always Below 1 Ω
      O148-23 (SI-) - O150-7 (VOI-) Always Below 1 Ω
      O148-22 (SI+) or O150-6 (VOI+) - Body ground Always 10 kΩ or higher
      O148-23 (SI-) or O150-7 (VOI-) - Body ground Always 10 kΩ or higher
      O150-8 (SLD1) - Body ground Always 10 kΩ or higher
      Result
      Proceed to
      OK
      NG

    OK

    PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE Click here

    NG

    REPAIR OR REPLACE HARNESS OR CONNECTOR
