TELEPHONE ANTENNA CORD INSTALLATION

PROCEDURE


  1. INSTALL NO. 3 ANTENNA CORD SUB-ASSEMBLY


    1. B008KDBC01
      *A for Type A
      *B for Type B
      *a Clamp
      *b Guide

      Engage the clamps and guide to install the No. 3 antenna cord sub-assembly.

    2. Install the bolt.

      Torque:
      for Type A
      10.5 N*m  { 107 kgf*cm, 8 ft.*lbf }
      for Type B
      10 N*m  { 102 kgf*cm, 7 ft.*lbf }

    3. Connect the connector.

  2. INSTALL NO. 2 ANTENNA CORD SUB-ASSEMBLY


    1. Type A:


      1. Remove the old double-sided tape from the roof headlining.

        B008KW4C01
        *A w/ Digital Audio Broadcasting Antenna - -
        *a Marking - -
        B008LZV Double-sided Tape B008LL0 Front

      2. Prepare an appropriate amount of new double-sided tape.

        Tech Tips

        Be careful not to touch the adhesive surface.

      3. Apply the double-sided tape to the roof headlining while aligning the tape with the markings on the roof headlining.

      4. Peel off the release paper from the double-sided tape.

      5. Engage the No. 2 antenna cord sub-assembly to the notch of the roof headlining.

        B008KZ0C01
        *a Marking Tape (A) *b Marking Tape (B)
        *c Adhesive Tape (A) *d Adhesive Tape (B)
        *e Protrusion *f Edge of the roof headlining
        *g Marking (A) *h Adjustment Area
        B008LL0 Front - -

      6. Align the marking tape (A) on the No. 2 antenna cord sub-assembly with the protrusion on the front of the roof headlining and wrap tape around the No. 2 antenna cord sub-assembly and protrusion of the roof headlining.

      7. Install the No. 2 antenna cord sub-assembly on the double-sided tape of the roof headlining from the marking tape (A) to the marking (A).

        Note


        • Make sure that there are no gaps between the roof headlining and No. 2 antenna cord sub-assembly, and that the No. 2 antenna cord sub-assembly is not twisted.

        • Make sure the No. 2 antenna cord assembly is securely installed. If any part of the No. 2 antenna cord sub-assembly is loose, it will cause an abnormal noise.

      8. Align the marking tape (B) on the No. 2 antenna cord sub-assembly with the edge of roof headlining on the roof headlining and secure the No. 2 antenna cord sub-assembly with the adhesive tape (A) as shown in the illustration.

        Note

        Make sure that there are no gaps between the roof headlining and No. 2 antenna cord sub-assembly, and that the No. 2 antenna cord sub-assembly is not twisted.

      9. Apply the adhesive tape (B) as shown in the illustration to secure the No. 2 antenna cord subassembly.

        Tech Tips

        Secure the extra length of the No. 2 antenna cord sub-assembly in the adjustment area as shown in the illustration.

    2. Type B:


      1. Align the marking tape (A) on the No. 2 antenna cord sub-assembly with the protrusion on the front of the roof headlining and wrap tape around the No. 2 antenna cord sub-assembly and protrusion of the roof headlining.

        B008LJ4C03
        *a Marking Tape (A) *b Marking Tape (B)
        *c Adhesive Tape (A) *d Adhesive Tape (B)
        *e Marking (A) *f Protrusion
        *g Edge of the roof headlining - -
        B008LL0 Front - -

      2. Install the No. 2 antenna cord sub-assembly on the butyl tape of the roof headlining from the marking tape (A) to the marking (A).

        Note


        • Make sure that there are no gaps between the roof headlining and No. 2 antenna cord sub-assembly, and that the No. 2 antenna cord sub-assembly is not twisted.

        • Make sure the No. 2 antenna cord assembly is securely installed. If any part of the No. 2 antenna cord sub-assembly is loose, it will cause an abnormal noise.

      3. Align the marking tape (B) on the No. 2 antenna cord sub-assembly with the edge of roof headlining on the roof headlining and secure the No. 2 antenna cord sub-assembly with the adhesive tape (A) as shown in the illustration.

        Note

        Make sure that there are no gaps between the roof headlining and No. 2 antenna cord sub-assembly, and that the No. 2 antenna cord sub-assembly is not twisted.

      4. Apply the adhesive tape (B) as shown in the illustration to secure the No. 2 antenna cord subassembly.

        Tech Tips

        Secure the extra length of the No. 2 antenna cord sub-assembly in the adjustment area as shown in the illustration.

  3. INSTALL ANTENNA CORD SUB-ASSEMBLY


    1. B008LBN

      Engage the guides to install the antenna cord sub-assembly.

  4. INSTALL ROOF HEADLINING

    Click here

  5. INSTALL NO. 3 HEATER TO REGISTER DUCT SUB-ASSEMBLY

    Click here

  6. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY

    Click here
