| C1511 |
Torque Sensor1 |
Torque sensor malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1512 |
Torque Sensor2 |
Torque sensor malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1513 |
Torque Sensor Deviation Excessive |
Torque sensor malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1514 |
Torque Sensor Power Supply Voltage |
Torque sensor malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1515 |
Torque Sensor Zero Point Adjustment Undone |
This DTC is stored when torque sensor zero point calibration has not been performed. |
EPS warning light: Comes on |
Zero point calibration is performed or the ignition switch is turned to ON again |
There is no malfunction if this DTC is not output again after performing zero point calibration. |
Click here
|
| C1516 |
Torque Sensor Zero Point Adjustment Incomplete |
Torque sensor zero point calibration is incomplete due to the steering wheel being touched during calibration. |
EPS warning light: Comes on |
The DTC is cleared |
There is no malfunction if this DTC is not output again after clearing the DTC and torque sensor calibration value, and performing zero point calibration. |
Click here
|
| C1521 |
Short in Motor Circuit |
Motor overcurrent |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1522 |
Power Supply Sensor |
Motor current sensor malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1523 |
Current Deviation Excessive |
Excessively large current deviation |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1528 |
Motor Rotation Angle Sensor |
Motor rotation angle sensor malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1531 |
ECU Malfunction |
ECU internal malfunction (CPU malfunction) |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1532 |
ECU Malfunction |
ECU internal malfunction (Peripheral circuit malfunction) |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1533 |
Temperature Sensor Circuit is Low or High |
ECU internal malfunction (Substrate temperature sensor malfunction) |
EPS warning light: Comes on |
The ECU judges the system has returned to normal |
- |
Click here
|
| C1534 |
EEPROM |
ECU internal malfunction (EEPROM error) |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1541 |
Vehicle Speed Signal |
A vehicle speed signal malfunction is detected |
EPS warning light: Comes on |
The ECU judges the system has returned to normal |
- |
Click here
|
| C1551 |
IG Power Supply Voltage |
When the PIG power supply voltage is normal, the IG power supply voltage is 18.5 V or higher |
EPS warning light: Comes on |
The ECU judges the system has returned to normal |
- |
Click here
|
| C1552 |
PIG Power Supply Voltage |
PIG power source circuit malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1554 |
Power Supply Relay Failure |
Power source relay circuit malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1555 |
Motor Relay Welding Failure |
Motor relay circuit malfunction |
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1567 |
Error in Matching of ECUs |
-
An incompatible ECM is detected
-
An incompatible main body ECU (multiplex network body ECU) is detected
-
An incompatible skid control ECU (brake actuator assembly) is detected
|
EPS warning light: Comes on |
Ignition switch is turned to ON again |
- |
Click here
|
| C1581 |
Assist Map Number Un-Writing |
Assist map not written in power steering ECU (rack and pinion power steering gear assembly) |
EPS warning light: Comes on |
Assist Map Writing is performed |
- |
Click here
|
| C1582 |
Assist Map Number Mismatch |
Assist map number mismatch |
EPS warning light: Does not come on |
Ignition switch is turned to ON again |
- |
Click here
|
| U0100 |
Lost Communication with ECM / PCM "A" |
Lost communication with ECM |
EPS warning light: When an error occurs during steering assist, the warning light does not illuminate. For errors that occur before assist (at the time of the decision to start assist), the warning light illuminates. |
The ECU judges the system has returned to normal |
- |
Click here
|
| U0126 |
Lost Communication With Steering Angle Sensor Module |
Lost communication with steering angle sensor |
EPS warning light: Comes on |
The ECU judges the system has returned to normal |
- |
Click here
|
| U0129 |
Lost Communication with Brake System Control Module |
Lost communication with skid control ECU (Brake actuator assembly) |
EPS warning light: Comes on |
The ECU judges the system has returned to normal |
- |
Click here
|
| U023A |
Lost Communication with Front Camera Module |
Lost communication with forward recognition camera |
EPS warning light: Does not come on |
The ECU judges the system has returned to normal |
w/ Forward Recognition Camera |
Click here
|
