SEAT MEMORY SWITCH REMOVAL

CAUTION / NOTICE / HINT

Tech Tips


  • Use the same procedure for RHD and LHD vehicles.

  • The following procedure is for LHD vehicles.

PROCEDURE


  1. REMOVE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WITH FRONT DOOR UPPER ARMREST BASE PANEL

    Click here

  2. REMOVE SEAT MEMORY SWITCH


    1. B00892B

      Disengage the 4 claws to remove the seat memory switch from the multiplex network master switch assembly with front door upper armrest base panel.
