SEAT MEMORY SWITCH INSTALLATION

PROCEDURE

1. INSTALL SEAT MEMORY SWITCH




   1.

      Engage the 4 claws to install the seat memory switch to the multiplex network master switch assembly with front door upper armrest base panel.

2. INSTALL MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WITH FRONT DOOR UPPER ARMREST BASE PANEL
