REAR COMBINATION LIGHT ASSEMBLY COMPONENTS
ILLUSTRATION
| *1 | TONNEAU COVER ASSEMBLY | - | - |
ILLUSTRATION
| *A | w/o Spare Tire | - | - |
| *1 | DECK BOARD ASSEMBLY | *2 | DECK FLOOR BOX LH |
| *3 | DECK FLOOR BOX RH | *4 | NO. 2 DECK BOARD SUB-ASSEMBLY |
| *5 | NO. 3 DECK BOARD SUB-ASSEMBLY | - | - |
ILLUSTRATION
| *A | w/ Spare Tire | *B | for Compact Size Spare Tire |
| *C | for Full Size Spare Tire | - | - |
| *1 | DECK BOARD ASSEMBLY | *2 | NO. 2 DECK BOARD SUB-ASSEMBLY |
| *3 | NO. 3 DECK BOARD SUB-ASSEMBLY | - | - |
ILLUSTRATION
| *A | w/ Spare Tire | *B | for Compact Size Spare Tire |
| *C | for Full Size Spare Tire | - | - |
| *1 | DECK FLOOR BOX LH | *2 | DECK FLOOR BOX RH |
| *3 | REAR DECK FLOOR BOX | *4 | SPARE TIRE |
ILLUSTRATION
| *A | w/o Spare Tire | *B | w/ Spare Tire |
| *1 | DECK TRIM SIDE PANEL ASSEMBLY LH | *2 | LUGGAGE HOLD BELT STRIKER ASSEMBLY |
| *3 | NO. 1 LUGGAGE COMPARTMENT TRIM HOOK | *4 | REAR FLOOR FINISH PLATE |
ILLUSTRATION
| *1 | REAR COMBINATION LIGHT ASSEMBLY LH | *2 | REAR COMBINATION LIGHT COVER LH |
| *3 | REAR COMBINATION LIGHT RETAINER LH | - | - |
ILLUSTRATION
| *1 | REAR COMBINATION LIGHT SOCKET AND WIRE SUB-ASSEMBLY LH | - | - |
