LUGGAGE COMPARTMENT DOOR OPENER SYSTEM PARTS LOCATION
ILLUSTRATION
ILLUSTRATION
| *1 | MAIN BODY ECU (NETWORK GATEWAY ECU) |
| *2 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY |
| *3 | LUGGAGE DOOR OPENING SWITCH ASSEMBLY |
| *4 | LUGGAGE DOOR CLOSER ASSEMBLY |
ILLUSTRATION
ILLUSTRATION
| *1 | MAIN BODY ECU (NETWORK GATEWAY ECU) |
| *2 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY |
| *3 | LUGGAGE DOOR OPENING SWITCH ASSEMBLY |
| *4 | LUGGAGE DOOR CLOSER ASSEMBLY |
