СВЕЧА НАКАЛИВАНИЯ СНЯТИЕ


  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL

    CAUTION:

    Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.

  2. REMOVE INTAKE PIPE ASSEMBLY


    1. A01E109

      Loosen the 2 intake pipe clamps.

    2. Remove the 2 bolts and intake pipe.

  3. REMOVE NO. 1 GLOW PLUG CONNECTOR


    1. Remove the nut and wire harness.

    2. Remove the 4 screw grommets, 4 nuts and glow plug connector.

  4. REMOVE GLOW PLUG ASSEMBLY


    1. A01DWQX

      Using a 12 mm deep socket wrench, remove the 4 glow plugs.
