BRAKE ACTUATOR (w/ VSC) REASSEMBLY


  1. INSTALL BRAKE ACTUATOR BOLT CUSHION


    1. Install the 3 brake actuator bolt cushions to the No. 1 brake actuator bracket.

  2. INSTALL BRAKE ACTUATOR CASE COLLAR


    1. Install the 3 brake actuator case collars to the brake actuator bolt cushion.

  3. INSTALL NO. 1 BRAKE ACTUATOR BRACKET


    1. Install the No. 1 brake actuator bracket to the brake actuator assembly with the 3 bolts.

      Torque:
      5.4 N*m  { 55 kgf*cm, 48 in.*lbf }

      Note


      • Do not remove the hole plug until the new brake actuator assembly is connected because it already contains brake fluid.

      • Insert the protrusion of the brake actuator case collar between the positioning claws of the No. 1 brake actuator bracket.

      • Insert the positioning pin of the No. 1 brake actuator bracket into the brake actuator bolt cushion of the brake actuator assembly.
