SEAT HEATER SWITCH REMOVAL

CAUTION / NOTICE / HINT

Tip:

  • Use the same procedure for RHD and LHD vehicles.

  • The procedure listed below is for LHD vehicles.

PROCEDURE

  1. REMOVE REAR CONSOLE BOX SUB-ASSEMBLY

    Click here

  2. REMOVE LOWER NO. 2 INSTRUMENT PANEL FINISH PANEL

    Click hereClick here

  3. REMOVE SEAT HEATER SWITCH LH

    1. B439088C01

      *A

      for LHD

      *B

      for RHD

      Detach the 2 claws to remove the seat heater switch LH.

  4. REMOVE SEAT HEATER SWITCH RH

    Tip:

    Use the same procedure described for the LH side.
