ELECTRICAL KEY OSCILLATOR(for Rear Floor) REMOVAL

PROCEDURE


  1. REMOVE REAR NO. 2 SEAT ASSEMBLY

    Click here

  2. REMOVE NO. 3 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY


    1. Turn back the rear floor carpet assembly.

    2. B005NKMC01
      *a Clamp (A)
      *b Clamp (B)
      B007WXX Connector
      B00803L Nut

      Disconnect the connector.

    3. Disengage the clamp (A).

    4. Remove the nut.

    5. Disengage the clamp (B) to remove the No. 3 indoor electrical key antenna assembly.

      Note

      Be careful when removing the No. 3 indoor electrical key antenna assembly. If the No. 3 indoor electrical key antenna assembly is dropped, replace it with a new one.
