VSC OFF SWITCH (w/ VSC) INSTALLATION

Tech Tips


  • Use the same procedure for the RH and LH sides.

  • The procedure listed below is for the LH side.


  1. INSTALL VSC OFF SWITCH


    1. Attach the 2 claws to install the VSC OFF switch to the No. 2 instrument cluster finish panel sub-assembly.

    2. Connect the connector.

  2. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY


    1. Attach the 6 claws and a hooks to install the instrument cluster finish panel sub-assembly.

  3. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY


    1. Attach the 4 claws to install the instrument cluster finish panel assembly.

  4. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL GARNISH


    1. Attach the 3 claws to install the instrument cluster finish panel garnish No. 1.

  5. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY


    1. for Standard Body:

      Attach the 14 claws to install the instrument cluster finish panel sub-assembly center.

    2. for Wide Body:

      Attach the 16 claws to install the instrument cluster finish panel sub-assembly center.

  6. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL GARNISH


    1. Attach the 3 claws to install the instrument cluster finish panel garnish No. 2.
