REAR SUNSHADE ASSEMBLY REMOVAL

CAUTION / NOTICE / HINT

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during rear sunshade assembly removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced
Replaced Part or Performed Procedure Necessary Procedure Effect/Inoperative Function when Necessary Procedure not Performed Link
Disconnect cable from negative battery terminal Perform steering sensor zero point calibration Lane Departure Alert System (w/ Steering Control)

Click here

Pre-collision System
Memorize steering angle neutral point Parking Assist Monitor System

Click here

Panoramic View Monitor System

Click here

CAUTION:

Some of these service operations affect the SRS airbag system. Read the precautionary notices concerning the SRS airbag system before servicing.

B0084SX

Click here

PROCEDURE


  1. REMOVE REAR SEAT ASSEMBLY (for Fold Down Seat Type)

    Click here

  2. REMOVE REAR SEAT ASSEMBLY (for Reclining Seat Type)

    Click here

  3. REMOVE CENTER STOP LIGHT SET

    Click here

  4. DISCONNECT REAR SEAT OUTER BELT ASSEMBLY LH

    Click here

  5. DISCONNECT REAR SEAT OUTER BELT ASSEMBLY RH

    Tech Tips

    Use the same procedure as for the LH side.

  6. REMOVE INNER ROOF SIDE GARNISH LH

    Click here

  7. REMOVE INNER ROOF SIDE GARNISH RH

    Tech Tips

    Use the same procedure as for the LH side.

  8. REMOVE REAR SEAT SHOULDER BELT HOLE COVER

    Click here

  9. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY

    Click here

  10. REMOVE ROOM PARTITION BOARD LH (for Fold Down Seat Type)

    Click here

  11. REMOVE ROOM PARTITION BOARD RH (for Fold Down Seat Type)

    Click here

  12. REMOVE NO. 1 UPPER BACK PANEL HOLE COVER


    1. Remove the No. 1 upper back panel hole cover.

  13. REMOVE NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY


    1. B0084HPC01
      B00847Z Remove in this Direction

      Disengage the 3 clips as shown in the illustration.

    2. B0086XVC01
      B00847Z Remove in this Direction

      Disengage the 5 guides to remove the No. 2 package tray trim panel assembly as shown in the illustration.

  14. REMOVE REAR WINDOW SHADE ASSEMBLY


    1. B0086CQN01

      Disconnect the connector.

    2. Remove the 3 bolts (A).

    3. Loosen the bolt (B) and remove the rear window shade assembly.

      Note

      Bolt (B) cannot be removed from the rear window shade assembly.
