FRONT SEAT ASSEMBLY(for Manual Seat) REASSEMBLY

CAUTION / NOTICE / HINT

CAUTION:


  • B0025TC

    Wear protective gloves. Sharp areas on the parts may injure your hands.

  • There is risk of injury.

Tech Tips


  • Use the same procedure for RHD and LHD vehicles.

  • The procedures listed below are for LHD vehicles.

  • Use the same procedure for the RH and LH sides.

  • The procedure listed below is for the LH side.

PROCEDURE


  1. INSTALL SEAT TRACK HANDLE SUB-ASSEMBLY LH


    1. Attach the claw and install the seat track handle sub-assembly LH.

      B0028UO

  2. INSTALL OCCUPANT DETECTION ECU (w/ Occupant Detection ECU)


    1. B00272H

      Attach the claw to install the occupant detection ECU.

  3. INSTALL FRONT SEAT WIRE RH (w/ Occupant Detection ECU)


    1. B0028SU

      Attach the wire harness clamp.

    2. B0028ISC01
      *a for Front Side

      Attach the clamp.

    3. B0026CTC01
      *a for Front Side

      Attach the clamp.

    4. B0028AHC01
      *a for Front Side

      Attach the clamp.

    5. B00278NC01
      *a for Front Side

      Connect the 2 connectors.

    6. Connect the 4 connectors and install front seat wire RH.

      B0025VK

  4. INSTALL FRONT SEAT CUSHION SPRING SUB-ASSEMBLY LH


    1. B0027ZSC01
      B0069FO Install in this Direction (1)
      B0068NX Install in this Direction (2)

      While rotating the part in install direction (1) shown in the illustration, attach the hook.

    2. Push in Install direction (2) shown in the illustration to attach the hook and install the front seat cushion spring sub-assembly LH.

  5. INSTALL FRONT SEAT CUSHION EDGE PROTECTOR LH


    1. B0028VBC01
      *A w/ Vertical Adjuster
      *B w/o Vertical Adjuster
      B0069FO Install in this Direction (1)
      B0068NX Install in this Direction (2)

      Push in installation direction (1) shown in the illustration to attach the guide.

    2. While expanding the part in installation direction (2) shown in the illustration, attach the claw.

    3. Install the front seat cushion edge protector LH with the screw.

  6. INSTALL FRONT SEAT CUSHION EDGE PROTECTOR RH

    Tech Tips

    Use the same procedure as for the LH side.

  7. INSTALL FRONT SEAT LOWER CUSHION SHIELD LH (w/ Vertical Adjuster)


    1. B0028KXC01
      B0069FO Install in this Direction (1)
      B0068NX Install in this Direction (2)

      Push in the installation direction (1) shown in the illustration.

    2. Push in the installation direction (2) shown in the illustration to attach the clip.

    3. B00251VC01
      B0069FO Install in this Direction

      Push the guide in the installation direction shown in the illustration.

    4. Install the front seat lower cushion shield LH with the screw.

  8. INSTALL FRONT SEAT LOWER CUSHION SHIELD RH (w/ Vertical Adjuster)

    Tech Tips

    Use the same procedure as for the LH side.

  9. INSTALL SEAT COVER WIRE


    1. B00256CN04

      Install the seat cover wire.

      Tech Tips


      • There are service parts available for wires of 1000 mm (3.28 ft.) or longer and formed wires.


      • When a wire that is less than 1000 mm (3.28 ft.) in length is needed, cut and shape a 1000 mm (3.28 ft.) supplied wire into the dimensions shown in the illustration.


      • Refer to the precautions when creating a wire.

        Click here

      Length
      A 170 mm (6.70 in.)
      B 150 mm (5.91 in.)
      C 230 mm (9.06 in.)
      D 270 mm (10.63 in.)
      E 290 mm (11.42 in.)

      Tech Tips

      The dimensions shown in the illustration are the length.

      A01SGX6

  10. INSTALL SEPARATE TYPE FRONT SEAT CUSHION COVER

    Tech Tips


    • Refer to the precautions on wrinkles to avoid creating any on the separate type front seat cushion cover when installing the seat cover.

      Click here


    • As shown in the illustration, fix all of the cover seam allowances in the same direction.

      B0026FJN08

    1. Temporarily install the separate type front seat cushion cover to the separate type front seat cushion pad.

    2. Using hog ring pliers, install the separate type front seat cushion cover to the separate type front seat cushion pad with 18 new hog rings in the order shown in the illustration.

      B0026FQC01
      *1 Hog Ring Pliers - -
      *a Cutout - -

      Note


      • Do not dirty or damage the separate type front seat cushion cover.


      • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seat cushion pad.

      Tech Tips

      Install the hog rings at the cutouts if they are there.

    3. Using hog ring pliers, connect the 2 straps of the separate type front seat cushion cover to the separate type front seat cushion pad with 2 new hog rings.

      B0026WUC01
      *1 Hog Ring Pliers - -

      Note


      • Do not dirty or damage the separate type front seat cushion cover.


      • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seat cushion pad.

  11. INSTALL SEAT CUSHION COVER WITH PAD


    1. While sliding the part in the direction indicated by the arrow shown in the illustration, align the J hook to install the seat cushion cover with pad.

      B0027NE

  12. INSTALL FRONT SEATBACK EDGE PROTECTOR (for Low-back Seat Type)


    1. A01SIHF

      Attach the claw to Install the 2 front seatback edge protectors.

  13. INSTALL FRONT SEATBACK SPRING SUB-ASSEMBLY LH (for Low-back Seat Type)


    1. B0025WHC01
      *1 Front No. 2 Seatback Hook
      B0069FO Install in this Direction (1)
      B0068NX Install in this Direction (2)

      Temporarily install the 2 front No. 2 seatback hooks to the front seatback spring sub-assembly LH.

    2. Push in installation direction (1) shown in the illustration to install the front seatback spring sub-assembly LH.

    3. Push in installation direction (2) shown in the illustration to temporarily the front seatback spring sub-assembly LH.

    4. B002681

      Attach the claw and install the 2 front seatback edge protectors.

  14. INSTALL FRONT NO. 2 SEATBACK HOOK (for Low-back Seat Type)


    1. B00283WC01
      B0069FO Install in this Direction

      Push up installation direction shown in the illustration to attach the claw to install the 2 front No. 2 seatback hooks.

  15. INSTALL FRONT SEAT AIRBAG ASSEMBLY LH (w/ Front Seat Side Airbag)

    for High-back Seat Type:

    Click here

    for Low-back Seat Type:

    Click here

  16. INSTALL SEAT COVER WIRE


    1. Install the seat cover wire.

      Tech Tips


      • There are service parts available for wires of 1000 mm (3.28 ft.) or longer and formed wires.


      • When a wire that is less than 1000 mm (3.28 ft.) in length is needed, cut and shape a 1000 mm (3.28 ft.) supplied wire into the dimensions shown in the illustration.


      • Refer to the precautions when creating a wire.

        Click here


      1. B0028GIN04

        for Hi-back Seat Type:

        Length
        A 150 mm (5.91 in.)
        B 290 mm (11.42 in.)
        C 420 mm (1.38 ft.)

        Tech Tips

        The dimensions shown in the illustration are the length.

        A01SGX6
      2. B0026FKN01

        for Low-back Seat Type, for Basic Style:

        Length
        A 290 mm (11.42 in.)
        B 420 mm (1.38 ft.)

        Tech Tips

        The dimensions shown in the illustration are the length.

        A01SGX6
      3. B0027J8N01

        for Low-back Seat Type, for High Style:

        Length
        A 170 mm (6.70 in.)
        B 200 mm (7.87 in.)
        C 420 mm (1.38 ft.)

        Tech Tips

        A01SGX6

        The dimensions shown in the illustration are the length.

  17. INSTALL SEPARATE TYPE FRONT SEATBACK COVER

    Tech Tips


    • Refer to the precautions on wrinkles to avoid creating any on the separate type front seatback cover when installing the seat cover.

      Click here


    • As shown in the illustration, fix all of the cover seam allowances in the same direction.

      B0024X5N01

    1. Set the separate type front seatback cover.

    2. for Hi-back Seat Type:


      1. Using hog ring pliers, install the separate type front seatback cover with 8 new hog rings in the order shown in the illustration.

        B0028T0C01
        *1 Hog Ring Pliers - -
        *a Cutout - -

        Note


        • Do not dirty or damage the separate type front seatback cover.


        • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seatback pad.

        Tech Tips

        Install the hog rings at the cutouts if they are there.

    3. for Low-back Seat Type, Basic Style:


      1. Using hog ring pliers, install the separate type front seatback cover with 6 new hog rings in the order shown in the illustration.

        B00291WC01
        *1 Hog Ring Pliers - -
        *a Cutout - -

        Note


        • Do not dirty or damage the separate type front seatback cover.


        • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seatback pad.

        Tech Tips

        Install the hog rings at the cutouts if they are there.

    4. for Low-back Seat Type, High Style:


      1. Using hog ring pliers, install the separate type front seatback cover with 12 new hog rings in the order shown in the illustration.

        B0025I3C01
        *1 Hog Ring Pliers - -
        *a Cutout - -

        Note


        • Do not dirty or damage the separate type front seatback cover.


        • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seatback pad.

        Tech Tips

        Install the hog rings at the cutouts if they are there.

  18. INSTALL SEATBACK COVER WITH PAD


    1. for Hi-back Seat Type:


      1. B0026ORC01
        B0069FO Install in this Direction

        Push in installation direction shown in the illustration to temporarily install the seatback cover with pad.

    2. for Low-back Seat Type:


      1. B0028X5C01
        B0069FO Install in this Direction

        Push in installation direction shown in the illustration to temporarily install the seatback cover with pad.

    3. w/ Front Seat Side Airbag, for Type B:


      1. B00295BC01
        *1 J Hook A
        *2 J Hook B
        B0069FO Install in this Direction

        Push in the installation direction shown in the illustration to attach the J hook A and J hook B.

        Tech Tips

        For RH seats, push up from below.

      2. B0024CBC01
        *1 J Hook B (J Hook A and J Hook B)
        *2 J Hook C
        B0069FO Install in this Direction

        Push in the installation direction shown in the illustration to attach the J hook B (J hook A and J hook B) and J hook C.

        Tech Tips

        For RH seats, push up from below.

      3. Install the new rivet to J hook B.

        B0028MTC01
        *A for LH seat *B for RH seat
        *1 J Hook A *2 J Hook B

        Tech Tips


        • For LH seats, install the top rivet.


        • For RH seats, install the bottom rivet.

      4. Place your hand at the position shown in the illustration and push in the install direction to attach the J hook B.

        B002543C01
        *1 J Hook A *2 J Hook B
        *3 J Hook C - -
        B0068AS Place Hand Here B0069FO Install in this Direction

    4. for Hi-back Seat Type:


      1. Using hog ring pliers, install the 2 new hog rings.

        B0024BHC01
        *1 Hog Ring Pliers - -

      2. Using hog ring pliers, install the 6 new hog rings.

        B0026HBC01
        *1 Hog Ring Pliers - -
        *a Cutout - -

        Note


        • Do not dirty or damage the separate type front seatback cover.


        • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seatback pad.

        Tech Tips

        Install the hog rings at the cutouts if they are there.

  19. INSTALL FRONT SEAT HEADREST SUPPORT (for Low-back Seat Type)


    1. B0028NMC01
      B0069FO Install in this Direction

      Push in the installation direction shown in the illustration to attach the claw and install the 2 front seat headrest supports.

    2. B0027IEC01
      B0069FO Install in this Direction

      for Basic Style:


      1. Pull up the installation direction shown in the illustration to attach the guide to the 2 straps.

    3. B0024FRC01
      B0069FO Install in this Direction

      Close the fasteners as shown in the illustration.

    4. Using hog ring pliers, install 6 new hog rings.

      B0025TKC07
      *1 Hog Ring Pliers - -
      *a Cutout - -

      Note


      • Do not dirty or damage the separate type front seatback cover.


      • Securely tighten the hog rings as shown in the illustration while making sure wrinkles do not form in the center of the fabric and separate type front seatback pad.

      Tech Tips

      Install the hog rings at the cutouts if they are there.

  20. INSTALL FRONT NO. 1 SEATBACK HOOK (for Low-back Seat Type)


    1. A01SHUB

      Install the claw and front No. 1 seatback hook.

  21. INSTALL RECLINING ADJUSTER INSIDE COVER LH


    1. B0027L6C01
      B0069FO Install in this Direction (1)
      B0068NX Install in this Direction (2)

      Push down installation direction (1) shown in the illustration.

    2. Rotate the part in installation direction (2) shown in the illustration and align the guide to install the reclining adjuster inside cover LH.

  22. INSTALL RECLINING ADJUSTER INSIDE COVER RH

    Tech Tips

    Use the same procedure as for the LH side.

  23. INSTALL FRONT SEATBACK FRAME SUB-ASSEMBLY LH


    1. B002729C01
      *A RH Side
      *B LH Side

      Install the 4 bolts and front seatback frame sub-assembly LH.

      Torque:
      42 N*m  { 428 kgf*cm, 31 ft.*lbf }
    2. B002551C01
      *A RH Side
      *B LH Side
      *1 Separate Type Front Seat Cushion Cover

      Attach the hook.

    3. B0024G8

      w/ Front Seat Side Airbag, w/ Seat Heater System:


      1. Attach the wire harness clamp and wire harness connector.

    4. B0025DG

      w/ Front Seat Side Airbag, w/o Seat Heater System:


      1. Attach the wire harness clamp.

    5. B002772

      w/o Front Seat Side Airbag, w/ Seat Heater System:


      1. Attach the wire harness clamp and wire harness connector.

    6. B0027JNC01
      *1 Wire Harness Clamp
      *2 Connector Clamp

      w/ Front Seat Side Airbag:


      1. Attach the wire harness clamp and connector clamp.

    7. B00295MC01
      *A w/o Front Seat Side Airbag
      *B w/ Front Seat Side Airbag
      *1 Wire Harness Clamp
      *2 Guide
      *3 Connector Clamp

      w/ Seat Heater System:


      1. Attach the wire harness clamp, connector clamp and guide.

    8. B002634

      Install the band in the position shown in the illustration.

  24. INSTALL FRONT SEAT INNER BELT ASSEMBLY LH

    Click here

  25. INSTALL FRONT SEAT INNER CUSHION SHIELD LH


    1. B0027HOC01
      B0069FO Install in this Direction

      Push in the installation direction shown in the illustration to attach the claw and guide.

    2. B0025BWC01
      B0069FO Install in this Direction

      Push in installation direction shown in the illustration and attach the claw to install the front seat inner cushion shield LH.

  26. INSTALL FRONT SEAT CUSHION SHIELD LH


    1. B0027PQC01
      B0069FO Install in this Direction

      Push in the installation direction shown in the illustration to attach the claw and guide.

    2. B002744C01
      B0069FO Install in this Direction

      Push in the installation direction shown in the illustration to attach the claw and guide.

    3. B0027W0C01
      *1 Clip A
      *2 Clip B

      Attach the clip B.

    4. Attach the claw.

    5. Attach the clip A and install the front seat cushion shield RH.

  27. INSTALL VERTICAL ADJUSTING HANDLE LH (w/ Vertical Adjuster)


    1. B0024VTC01
      B0069FO Install in this Direction

      With the reclining adjuster release handle LH pulled up.

    2. Attach the guide, and then push in the installation direction shown in the illustration to install the vertical adjusting handle LH.

    3. A01SHZ8

      Install the screw.

  28. INSTALL RECLINING ADJUSTER RELEASE HANDLE LH


    1. B002802C01
      B0069FO Install in this Direction

      With the reclining adjuster release handle LH pulled up.

    2. Push in the installation direction shown in the illustration and attach the claw to install the reclining adjuster release handle LH.

  29. INSTALL SEAT ADJUSTER COVER CAP LH


    1. B0026ZVC01
      B0069FO Install in this Direction

      Push in the installation direction shown in the illustration to install the 2 seat adjuster cover caps LH.

  30. INSTALL FRONT SEAT HEADREST ASSEMBLY (for Low-back Seat Type)


    1. B0028AIC01
      B006964 Apply Silicon

      Apply silicon lubricant to the application area.

      Tech Tips

      The application area shown in the illustration is 20 + / -10 mm.

    2. Install the front seat headrest assembly.
