TIRE PRESSURE WARNING INITIATOR(for Front Side) REMOVAL

PROCEDURE

1. REMOVE FRONT WHEEL LH

   Click here

2. REMOVE FRONT TIRE PRESSURE MONITOR INITIATOR




   1. Pull back the front fender liner LH so that the front tire pressure monitor initiator can be removed.

   2.

      Remove the nut.

   3. Disengage the hook to remove the front tire pressure monitor initiator.

   4. Disconnect the connector from the front tire pressure monitor initiator.
