VACUUM RESERVOIR(for 5L-E) COMPONENTS

ILLUSTRATION

A01SCXMC01
*1 NO. 1 VACUUM HOSE CONNECTOR *2 UNION TO CHECK VALVE HOSE
*3 VACUUM RESERVOIR SUB-ASSEMBLY *4 VACUUM RESERVOIR VACUUM CHECK VALVE ASSEMBLY
*5 SUCTION HOSE SUB-ASSEMBLY - -
B0068CQ N*m (kgf*cm, ft.*lbf) : Specified torque - -
