REAR SEAT OUTER BELT ASSEMBLY REMOVAL

CAUTION / NOTICE / HINT

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during rear seat outer belt assembly removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced
Replaced Part or Performed Procedure Necessary Procedure Effect/Inoperative Function when Necessary Procedure not Performed Link
Disconnect cable from negative battery terminal Perform steering sensor zero point calibration Lane departure alert system (w/ Steering Control)

Click here

Pre-collision system
Memorize steering angle neutral point Parking assist monitor system

Click here

CAUTION:


  • Wear protective gloves. Sharp areas on the parts may injure your hands.

  • B0084SX

    Be sure to read Precaution thoroughly before servicing.

    Click here

PROCEDURE


  1. PRECAUTION

    Note

    After turning the ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work.

    Click here

  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL

    for 2AR-FE:

    Click here

    for A25A-FKS:

    Click here

    for 2GR-FKS:

    Click here

    CAUTION:


    • Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.

    • If an airbag deploys for any reason, it may cause a serious injury.

    B0087PP

  3. DISCONNECT REAR CENTER SEAT OUTER BELT ASSEMBLY (for Fold Down Seat Type)

    Click here

  4. REMOVE REAR SEAT CUSHION ASSEMBLY (for Fold Down Seat Type)

    Click here

  5. REMOVE REAR SEAT CUSHION LOCK HOOK (for Fold Down Seat Type)

    Click here

  6. DISCONNECT REAR DOOR OPENING TRIM WEATHERSTRIP LH (for Fold Down Seat Type)

    Click here

  7. REMOVE REAR SIDE SEATBACK ASSEMBLY LH (for Fold Down Seat Type)

    Click here

  8. DISCONNECT REAR DOOR OPENING TRIM WEATHERSTRIP RH (for Fold Down Seat Type)

    Tech Tips

    Use the same procedure as for the LH side.

  9. REMOVE REAR SIDE SEATBACK ASSEMBLY RH (for Fold Down Seat Type)

    Tech Tips

    Use the same procedure as for the LH side.

  10. REMOVE REAR SEAT ASSEMBLY (for Reclining Seat Type)

    Click here

  11. REMOVE INNER ROOF SIDE GARNISH LH

    Click here

  12. REMOVE INNER ROOF SIDE GARNISH RH

    Tech Tips

    Use the same procedure as for the LH side.

  13. DISCONNECT REAR SEAT OUTER BELT ASSEMBLY LH


    1. B0084AI

      Remove the bolt to disconnect the floor anchor of the rear seat outer belt assembly LH.

  14. DISCONNECT REAR SEAT OUTER BELT ASSEMBLY RH

    Tech Tips

    Use the same procedure as for the LH side.

  15. REMOVE CENTER STOP LIGHT SET

    Click here

  16. REMOVE REAR SEAT SHOULDER BELT HOLE COVER


    1. B0087XP

      Disengage the 2 claws and 2 guides to remove the rear seat shoulder belt hole cover.

      Tech Tips

      Use the same procedure for the other rear seat shoulder belt hole covers.

  17. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade)


    1. Fold the rear seatback assembly LH and rear seatback assembly RH forward.

    2. B0088YM

      Remove the 2 clips.

    3. B0085XZ

      Disengage the 3 clips and 5 guides.

    4. Pass the 3 rear seat belt floor anchors through the package tray trim panel assembly then remove the package tray trim panel assembly.

  18. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade)


    1. B0085AF

      Disengage the 3 clips.

    2. Pass the 3 rear seat belt floor anchors through the package tray trim panel assembly then remove the package tray trim panel assembly.

  19. REMOVE REAR SEAT OUTER BELT ASSEMBLY LH


    1. B0089N3C01
      *a Protective Tape
      *b Locking Button
      *c Release

      Using a screwdriver, pull out the locking button as shown in the illustration to release the lock and disconnect the pretensioner connector.

      Tech Tips

      Tape the screwdriver tip before use.

    2. B0088C6

      Remove the 2 bolts.

    3. Disengage the guide to remove the rear seat outer belt assembly LH.

  20. REMOVE REAR SEAT OUTER BELT ASSEMBLY RH

    Tech Tips

    Use the same procedure as for the LH side.

  21. REMOVE REAR SEAT BELT RETRACTOR COVER


    1. B00844IC01
      B00847Z Remove in this Direction

      Remove the rear seat belt retractor cover as shown in the illustration.

      Tech Tips

      Use the same procedure for the RH side and LH side.
