ELECTRONICALLY CONTROLLED BRAKE SYSTEM PARTS LOCATION
ILLUSTRATION
| *A | for LHD | - | - |
| *1 | BRAKE ACTUATOR ASSEMBLY | *2 | FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY LH |
| *3 | SKID CONTROL ECU ASSEMBLY | *4 | BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY - BRAKE FLUID LEVEL WARNING SWITCH |
| *5 | NO. 3 ENGINE ROOM RELAY BLOCK - ABS MOTOR NO. 1 RELAY - ABS MOTOR NO. 2 RELAY |
*6 | BRAKE CONTROL POWER SUPPLY ASSEMBLY |
| *7 | FRONT AXLE HUB SUB-ASSEMBLY RH - FRONT SPEED SENSOR ROTOR RH - FRONT SPEED SENSOR RH |
*8 | SKID CONTROL SENSOR WIRE RH |
| *9 | FRONT AXLE HUB SUB-ASSEMBLY LH - FRONT SPEED SENSOR ROTOR LH - FRONT SPEED SENSOR LH |
*10 | SKID CONTROL SENSOR WIRE LH |
| *11 | NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY - SEMICONDUCTOR PWR INTEGRATION ECU - ABS-MAIN 1 FUSE - ABS-MAIN 2 FUSE - ABS-MAIN 3 FUSE - ABS NO. 1 FUSE - ABS NO. 2 FUSE - STOP FUSE - P/I-B FUSE - MPX-B NO. 1 FUSE - ENG-IG NO. 2 FUSE |
*12 | POWER STEERING ECU ASSEMBLY |
| *13 | REAR AXLE HUB AND BEARING ASSEMBLY RH - REAR SPEED SENSOR ROTOR RH |
*14 | REAR SPEED SENSOR RH |
| *15 | REAR AXLE HUB AND BEARING ASSEMBLY LH - REAR SPEED SENSOR ROTOR LH |
*16 | REAR SPEED SENSOR LH |
ILLUSTRATION
| *A | for RHD | - | - |
| *1 | BRAKE ACTUATOR ASSEMBLY | *2 | FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY RH |
| *3 | SKID CONTROL ECU ASSEMBLY | *4 | BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY - BRAKE FLUID LEVEL WARNING SWITCH |
| *5 | NO. 3 ENGINE ROOM RELAY BLOCK - ABS MOTOR NO. 1 RELAY - ABS MOTOR NO. 2 RELAY |
*6 | BRAKE CONTROL POWER SUPPLY ASSEMBLY |
| *7 | FRONT AXLE HUB SUB-ASSEMBLY RH - FRONT SPEED SENSOR ROTOR RH - FRONT SPEED SENSOR RH |
*8 | SKID CONTROL SENSOR WIRE RH |
| *9 | FRONT AXLE HUB SUB-ASSEMBLY LH - FRONT SPEED SENSOR ROTOR LH - FRONT SPEED SENSOR LH |
*10 | SKID CONTROL SENSOR WIRE LH |
| *11 | NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY - SEMICONDUCTOR PWR INTEGRATION ECU - ABS-MAIN 1 FUSE - ABS-MAIN 2 FUSE - ABS-MAIN 3 FUSE - ABS NO. 1 FUSE - ABS NO. 2 FUSE - STOP FUSE - P/I-B FUSE - MPX-B NO. 1 FUSE - ENG-IG NO. 2 FUSE |
*12 | POWER STEERING ECU ASSEMBLY |
| *13 | REAR AXLE HUB AND BEARING ASSEMBLY RH - REAR SPEED SENSOR ROTOR RH |
*14 | REAR SPEED SENSOR RH |
| *15 | REAR AXLE HUB AND BEARING ASSEMBLY LH - REAR SPEED SENSOR ROTOR LH |
*16 | REAR SPEED SENSOR LH |
ILLUSTRATION
| *A | for LHD | - | - |
| *1 | COMBINATION SWITCH ASSEMBLY | *2 | PARKING BRAKE SWITCH ASSEMBLY |
| *3 | STOP LIGHT SWITCH ASSEMBLY | *4 | HYBRID VEHICLE CONTROL ECU ASSEMBLY |
| *5 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) | *6 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY - CAPACITOR FUSE - ECU-IG1 NO. 1 FUSE - IG1 NO. 2 FUSE - IGN NO. 2 FUSE |
| *7 | BRAKE PEDAL STROKE SENSOR ASSEMBLY | *8 | COMBINATION METER ASSEMBLY - ABS WARNING LIGHT - BRAKE WARNING LIGHT / RED (MALFUNCTION) - BRAKE WARNING LIGHT / YELLOW (MINOR MALFUNCTION) - SLIP INDICATOR LIGHT - VSC OFF INDICATOR LIGHT - MULTI-INFORMATION DISPLAY (TRC OFF MESSAGE) - METER BUZZER |
| *9 | STEERING ANGLE SENSOR | *10 | DLC3 |
| *11 | YAW RATE AND ACCELERATION SENSOR | *12 | VSC OFF SWITCH |
ILLUSTRATION
| *A | for RHD | - | - |
| *1 | COMBINATION SWITCH ASSEMBLY | *2 | PARKING BRAKE SWITCH ASSEMBLY |
| *3 | STOP LIGHT SWITCH ASSEMBLY | *4 | HYBRID VEHICLE CONTROL ECU ASSEMBLY |
| *5 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) | *6 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY - CAPACITOR FUSE - ECU-IG1 NO. 1 FUSE - IG1 NO. 2 FUSE - IGN NO. 2 FUSE |
| *7 | BRAKE PEDAL STROKE SENSOR ASSEMBLY | *8 | COMBINATION METER ASSEMBLY - ABS WARNING LIGHT - BRAKE WARNING LIGHT / RED (MALFUNCTION) - BRAKE WARNING LIGHT / YELLOW (MINOR MALFUNCTION) - SLIP INDICATOR LIGHT - VSC OFF INDICATOR LIGHT - MULTI-INFORMATION DISPLAY (TRC OFF MESSAGE) - METER BUZZER |
| *9 | STEERING ANGLE SENSOR | *10 | DLC3 |
| *11 | YAW RATE AND ACCELERATION SENSOR | *12 | VSC OFF SWITCH |
