REAR LIGHT ASSEMBLY REMOVAL

CAUTION / NOTICE / HINT

Tech Tips


  • Use the same procedure for the RH side and LH side.

  • The following procedure is for the LH side.

PROCEDURE


  1. REMOVE LUGGAGE COMPARTMENT DOOR COVER

    Click here

  2. REMOVE REAR LIGHT ASSEMBLY


    1. for LED Type Back-up Light or Type A Bulb Type Back-up Light:


      1. B0085RL

        Disconnect the connector.

      2. Remove the 3 nuts.

      3. Disengage the clip to remove the rear light assembly.

    2. for Type B Bulb Type Back-up Light:


      1. B00873P

        Disconnect the connector.

      2. Remove the 3 nuts.

      3. Disengage the clip to remove the rear light assembly.
