ROOF HEADLINING(for Smart Cab) REMOVAL

CAUTION / NOTICE / HINT

Tech Tips


  • Use the same procedure for RHD and LHD vehicles.

  • The procedure listed below is for LHD vehicles.

CAUTION:

w/ Airbag System:

B0027VM

Some of these service operations affect the SRS airbag system. Read the precautionary notices concerning the SRS airbag system before servicing.

Click here

PROCEDURE


  1. PRECAUTION (w/ Airbag System)

    Note

    After turning the ignition switch off, waiting time may be required before disconnecting the cable from the battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice before proceeding with work.

    Click here

  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (w/ Airbag System)

    CAUTION:

    Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system.

    Note

    When disconnecting the cable, some systems need to be initialized after the cable is reconnected.

    Click here

  3. REMOVE FRONT SEAT ASSEMBLY LH

    Click here

  4. REMOVE FRONT SEAT ASSEMBLY RH

    Click here

  5. REMOVE ASSIST GRIP SUB-ASSEMBLY (w/ Assist Grip)

    Click here

  6. REMOVE FRONT PILLAR GARNISH LH

    Click here

  7. REMOVE FRONT PILLAR GARNISH RH

    Click here

  8. REMOVE REAR SEAT CUSHION ASSEMBLY (for RHD)

    Click here

  9. REMOVE BACK PANEL TRIM


    1. B0025ZEC01
      *a Protective Tape

      Put protective tape around the back panel trim.

    2. B00272QC01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the claw and clip and remove the back panel trim.

  10. REMOVE LOWER QUARTER TRIM PANEL LH


    1. B00281I

      for RHD:


      1. Remove the bolt and disconnect the rear seat outer belt assembly LH.

    2. B0024F6C01
      *1 Front Door Opening Trim Weatherstrip LH

      Disconnect the front door opening trim weatherstrip LH in the range shown in the illustration.

    3. B0028Y7C01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the claw and clip and remove the lower quarter trim panel LH.

  11. REMOVE LOWER QUARTER TRIM PANEL RH


    1. B00257X

      for RHD:


      1. Remove the bolt and disconnect the rear seat outer belt assembly RH.

    2. B0028C6C01
      *1 Front Door Opening Trim Weatherstrip RH

      Disconnect the front door opening trim weatherstrip RH in the range shown in the illustration.

    3. B0024PRC01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the claw and clip and remove the lower quarter trim panel RH.

  12. REMOVE SEAT BELT ANCHOR COVER CAP (for RHD)

    Tech Tips

    Use the same procedure for both seat belt anchor cover caps.


    1. B0028VSC01
      *a Protective Tape

      Put protective tape around the seat belt anchor cover cap.

    2. B00273TC01
      *a Protective Tape
      B0068AS Insert Thin-bladed Screwdriver Here
      B0069FO Remove in this Direction

      Insert a thin-bladed screwdriver at the position shown in the illustration and detach the claw and remove the seat belt anchor cover cap.

      Tech Tips

      Tape the thin-bladed screwdriver tip before use.

  13. REMOVE QUARTER INSIDE TRIM BOARD LH


    1. B0026P3

      for RHD:


      1. Remove the bolt and disconnect the rear seat outer belt assembly LH.

    2. B00278VC01
      *1 Front Door Opening Trim Weatherstrip LH

      Disconnect the front door opening trim weatherstrip LH in the range shown in the illustration.

    3. B0026OFC01
      B0068AS Insert Clip Remover Here
      B0069FO Remove in this Direction

      Insert a clip remover at the position shown in the illustration and pull as shown to detach the clip and remove the quarter inside trim board LH.

  14. REMOVE QUARTER INSIDE TRIM BOARD RH


    1. B0024ED

      for RHD:


      1. Remove the bolt and disconnect the rear seat outer belt assembly RH.

    2. B0024BOC01
      *1 Front Door Opening Trim Weatherstrip RH

      Disconnect the front door opening trim weatherstrip RH in the range shown in the illustration.

    3. B002862C01
      B0068AS Insert Clip Remover Here
      B0069FO Remove in this Direction

      Insert a clip remover at the position shown in the illustration and pull as shown to detach the clip and remove the quarter inside trim board RH.

  15. REMOVE MAP LIGHT ASSEMBLY

    Click here

  16. REMOVE NO. 1 ROOM LIGHT ASSEMBLY

    Click here

  17. REMOVE VISOR BRACKET COVER LH


    1. Open the visor assembly LH.

    2. B002505C01
      *a Protective Tape
      B0068AS Insert Thin-bladed Screwdriver Here

      Insert a thin-bladed screwdriver at the position shown in the illustration and detach the claw and remove the visor bracket cover LH.

      Tech Tips

      Tape the thin-bladed screwdriver tip before use.

  18. REMOVE VISOR BRACKET COVER RH


    1. Open the visor assembly RH.

    2. B0025D5C01
      *a Protective Tape
      B0068AS Insert Thin-bladed Screwdriver Here

      Insert a thin-bladed screwdriver at the position shown in the illustration and detach the claw and remove the visor bracket cover RH.

      Tech Tips

      Tape the thin-bladed screwdriver tip before use.

  19. REMOVE VISOR ASSEMBLY LH


    1. B0027W6

      Remove the 2 screws.

    2. B0027NGC01
      B0069FO Remove in this Direction (1)
      B0068NX Remove in this Direction (2)

      Pull in the direction (1) shown in the illustration to disconnect the visor assembly LH from the visor holder.

    3. Pull in the direction (2) shown in the illustration to remove the visor assembly LH.

  20. REMOVE VISOR ASSEMBLY RH


    1. B0025D8

      Remove the 2 screws.

    2. B0026TNC01
      B0069FO Remove in this Direction (1)
      B0068NX Remove in this Direction (2)

      Pull in the direction (1) shown in the illustration to disconnect the visor assembly RH from the visor holder.

    3. Pull in the direction (2) shown in the illustration to remove the visor assembly RH.

  21. REMOVE VISOR HOLDER

    Tech Tips

    Use the same procedure for both visor holders.


    1. B0024ZPC01
      B0069FO Remove in this Direction (1)
      B0068NX Remove in this Direction (2)

      Turn the visor holder clockwise approximately 45° and pull it out as shown in the illustration.

    2. Detach the claw and remove the visor holder.

  22. REMOVE ASSIST GRIP SUB-ASSEMBLY

    Tech Tips

    w/ Assist Grip:

    Use the same procedure for both assist grip sub-assemblies.


    1. B0028RZC01
      *a Protective Tape

      Put protective tape around the assist grip sub-assembly.

    2. B00261UC01
      *a Protective Tape
      B0068AS Insert Thin-bladed Screwdriver Here
      B0069FO Remove in this Direction

      Insert a thin-bladed screwdriver at the position shown in the illustration and detach the claw and open the assist grip cover.

      Tech Tips

      Tape the thin-bladed screwdriver tip before use.

    3. B0026VD

      Remove the 2 bolts and assist grip sub-assembly.

  23. REMOVE FRONT ROOF SIDE RAIL GARNISH LH


    1. B00247NC01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the clip and remove the front roof side rail garnish LH.

  24. REMOVE FRONT ROOF SIDE RAIL GARNISH RH


    1. B0025J4C01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the clip and remove the front roof side rail garnish RH.

  25. REMOVE ROOF HEADLINING SERVICE HOLE COVER (w/o Assist Grip)


    1. B00278A

      Using a clip remover, remove the 2 roof headlining service hole covers.

  26. REMOVE ROOF HEADLINING ASSEMBLY


    1. B0027M0

      Disconnect the connector and detach the clamp from the front pillar LH.

    2. B0026MPC01
      *1 Front Door Opening Trim Weatherstrip LH

      Disconnect the front door opening trim weatherstrip LH in the range shown in the illustration.

    3. B0028X9C01
      *1 Front Door Opening Trim Weatherstrip RH

      Disconnect the front door opening trim weatherstrip RH in the range shown in the illustration.

    4. B00286K

      Using a clip remover, remove the 3 clips.

    5. B0026TPC01
      B0069FO Remove in this Direction

      Turn the roof headlining assembly diagonally and bend slightly to remove it from the front door.

      Note


      • Make sure wrinkles do not form in the roof headlining assembly during removal.

      • Make sure that the roof headlining assembly does not get caught on anything as it may become bent or damaged.

      • Do not damage the roof headlining assembly or vehicle interior.

  27. REMOVE FRONT SIDE RAIL SPACER LH (w/o Curtain Shield Airbag)


    1. B00260K

      Detach the claw and remove the front side rail spacer LH.

  28. REMOVE FRONT SIDE RAIL SPACER RH (w/o Curtain Shield Airbag)


    1. B0024KW

      Detach the claw and remove the front side rail spacer RH.

  29. REMOVE REAR SIDE RAIL SPACER LH (w/o Curtain Shield Airbag)


    1. B0024XZ

      Detach the claw and remove the rear side rail spacer LH.

  30. REMOVE REAR SIDE RAIL SPACER RH (w/o Curtain Shield Airbag)


    1. B0025F1

      Detach the claw and remove the rear side rail spacer RH.

  31. REMOVE REAR NO. 2 SIDE RAIL SPACER LH (w/o Curtain Shield Airbag)


    1. B002870

      Detach the claw and remove the rear No. 2 side rail spacer LH.

  32. REMOVE REAR NO. 2 SIDE RAIL SPACER RH (w/o Curtain Shield Airbag)


    1. B0026XI

      Detach the claw and remove the rear No. 2 side rail spacer RH.

  33. REMOVE FRONT DOOR SCUFF PLATE LH


    1. B0028RTC01
      *a Protective Tape

      Put protective tape around the front door scuff plate LH.

    2. B0024G3C01
      B0068AS Insert Moulding Remover D Here
      B0069FO Remove in this Direction

      Insert moulding remover D at the position shown in the illustration and pull as shown to detach the clip and claw and remove the front door scuff plate LH.

  34. REMOVE FRONT DOOR SCUFF PLATE RH


    1. B0025D6C01
      *a Protective Tape

      Put protective tape around the front door scuff plate RH.

    2. B00250KC01
      B0068AS Insert Moulding Remover D Here
      B0069FO Remove in this Direction

      Insert moulding remover D at the position shown in the illustration and pull as shown to detach the clip and claw and remove the front door scuff plate RH.

  35. REMOVE LUGGAGE COMPARTMENT SIDE COVER LH


    1. B002753C01
      *1 Front Door Opening Trim Weatherstrip LH

      Disconnect the front door opening trim weatherstrip LH in the range shown in the illustration.

    2. B0024C0C01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the claw and remove the luggage compartment side cover LH.

  36. REMOVE LUGGAGE COMPARTMENT SIDE COVER RH


    1. B00271PC01
      *1 Front Door Opening Trim Weatherstrip RH

      Disconnect the front door opening trim weatherstrip RH in the range shown in the illustration.

    2. B0024Y3C01
      B0068AS Place Hands Here
      B0069FO Remove in this Direction

      Place your hands at the position shown in the illustration and pull as shown to detach the claw and remove the luggage compartment side cover RH.
