OIL LEVEL SENSOR REMOVAL

CAUTION / NOTICE / HINT

The necessary procedures (adjustment, calibration, initialization, or registration) that must be performed after parts are removed and installed, or replaced during oil level sensor removal/installation are shown below.

Necessary Procedure After Parts Removed/Installed/Replaced
Replaced Part or Performed Procedure Necessary Procedure Effect/Inoperative Function when Necessary Procedure not Performed Link
Battery terminal is disconnected/reconnected Perform steering sensor zero point calibration Lane departure alert system (w/ Steering Control)

Click here

Pre-collision system
Memorize steering angle neutral point Parking assist monitor system

Click here

Panoramic view monitor system

Click here

Replacement of ECM Vehicle Identification Number (VIN) registration MIL comes on

Click here

Perform code registration (Immobiliser system) Engine start function See Service Bulletin for the registration method.

  • Replacement of engine assembly

  • Gas leak from exhaust system is repaired

 Inspection after repair

  • Poor idle, etc.

  • Engine start function, etc.

Click here

Replacement of automatic transaxle assembly

Perform the following procedures in the order shown:


  1. Reset Memory

  2. Input transaxle compensation code into ECM

  3. Perform road test to allow ECM to learn

  • Large shift shock

  • Deterioration of fuel efficiency

Click here for U761E Initialization

Click here for U761E Registration

Replacement of ECM

(If possible, read the transaxle compensation code from the previous ECM)

 Possible

Perform the following procedures in the order shown:


  1. Reset Memory

  2. Transfer transaxle compensation code

  3. Perform road test to allow ECM to learn
Impossible

Perform the following procedures in the order shown:


  1. Reset Memory

  2. Reset transaxle compensation code

  3. Perform road test to allow ECM to learn
Replacement of ECM Perform code registration (Immobiliser function)

  • Wireless door lock control system

  • Smart Entry and Start System (for Entry Function)

  • Smart Entry and Start System (for Start Function)

  • Steering lock function

 See Service Bulletin for the registration method.
Suspension, tires, etc.*1 Rear television camera assembly optical axis (Back camera position setting) Parking assist monitor system

Click here for Initialization

Click here for Calibration

  • Television camera controller initialization

  • Adjust steering angle

  • Rear television camera assembly optical axis (Back camera position setting)

 Panoramic view monitor system

Click here for Initialization

Click here for Calibration
Replacement of front bumper assembly Front television camera view adjustment
Front wheel alignment adjustment Perform system variant learning and acceleration sensor zero point calibration.

  • VSC disabled or malfunctioning

  • DTCs are output

  • Slip indicator light illuminated

  • ABS warning light illuminated

Click here

*1: The vehicle height changes because of suspension or tire replacement.

PROCEDURE


  1. INSTALL ENGINE ASSEMBLY TO ENGINE STAND

    Click here

  2. REMOVE OIL PAN SUB-ASSEMBLY

    Click here

  3. REMOVE ENGINE OIL LEVEL SENSOR


    1. Disconnect the engine oil level sensor connector.

    2. B00872F

      Remove the clip from the engine oil level sensor.

    3. B0083IF

      Disengage the clamp.

    4. Remove the 2 bolts and engine oil level sensor.
