AIR CONDITIONING SYSTEM PARTS LOCATION
ILLUSTRATION
| *1 | AIR CONDITIONER PRESSURE SENSOR | *2 | COOLER (AMBIENT TEMP. SENSOR) THERMISTOR |
| *3 | COMPRESSOR ASSEMBLY WITH PULLEY (w/ Stop and Start System) | *4 | COOLER COMPRESSOR ASSEMBLY (w/o Stop and Start System) |
| *5 | PTC HTR NO. 1 RELAY (w/ PTC Heater) | *6 | PTC HTR NO. 2 RELAY (w/ PTC Heater) |
| *7 | PTC HTR NO. 3 RELAY (w/ PTC Heater) | *8 | SMOG VENTILATION SENSOR (w/ Smog Ventilation Sensor) |
| *9 | POWER STEERING ECU ASSEMBLY | *10 | MAGNETIC CLUTCH ASSEMBLY (w/o Stop and Start System) |
| *11 | COMPRESSOR SOLENOID | *12 | A/C LOCK SENSOR (w/o Stop and Start System) |
| *13 | OUTER MIRROR CONTROL ECU ASSEMBLY LH | *14 | OUTER MIRROR CONTROL ECU ASSEMBLY RH |
| *15 | FORWARD RECOGNITION CAMERA (w/ Pre-crash Safety System) | *16 | BRAKE ACTUATOR ASSEMBLY (SKID CONTROL ECU) |
| *17 | COOLER CONDENSER ASSEMBLY | *18 | ECM (w/o Stop and Start System) |
| *19 | ECM (w/ Stop and Start System) | *20 | NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY - ECU-IG1 NO. 8 FUSE - HTR FUSE - PTC HTR NO. 1 FUSE (w/ PTC Heater) - PTC HTR NO. 2 FUSE (w/ PTC Heater) - PTC HTR NO. 3 FUSE (w/ PTC Heater) - ALT FUSE (w/o Stop and Start System) - FL MAIN FUSE (w/o Stop and Start System) - RADIO NO. 2 FUSE (w/o Stop and Start System) |
| *21 | SEMICONDUCTOR PWR INTEGRATION ECU (w/o Stop and Start System) | - | - |
ILLUSTRATION
| *A | for LHD | - | - |
| *1 | COMBINATION SWITCH ASSEMBLY (ECO MODE SWITCH) | *2 | COOLER (ROOM TEMP. SENSOR) THERMISTOR |
| *3 | AUTOMATIC LIGHT CONTROL SENSOR | *4 | COMBINATION METER ASSEMBLY |
| *5 | DLC3 | *6 | RADIO RECEIVER ASSEMBLY (A/C CONTROL PANEL) |
| *7 | ION GENERATOR SUB-ASSEMBLY (w/ Ion Generator) | *8 | AIR CONDITIONING AMPLIFIER ASSEMBLY |
| *9 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) | *10 | MULTI-DISPLAY ASSEMBLY (for 8 Inch Display) |
| *11 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY - ECU-B NO. 2 FUSE - ECU-IG1 NO. 2 FUSE - ECU-IG1 NO. 3 FUSE - ECU-ACC FUSE (w/o Stop and Start System) |
*12 | AIRBAG SENSOR ASSEMBLY |
| *13 | ENGINE STOP AND START ECU (w/ Stop and Start System) | *14 | METER MIRROR SUB-ASSEMBLY (w/ Headup Display System) |
| *15 | 4WD ECU ASSEMBLY (for AWD) | *16 | DRIVING SUPPORT ECU ASSEMBLY (w/ Pre-crash Safety System) |
| *17 | ACCESSORY METER ASSEMBLY (for 12.3 Inch Display) | - | - |
ILLUSTRATION
| *A | for RHD | - | - |
| *1 | COMBINATION SWITCH ASSEMBLY (ECO MODE SWITCH) | *2 | COOLER (ROOM TEMP. SENSOR) THERMISTOR |
| *3 | AUTOMATIC LIGHT CONTROL SENSOR | *4 | COMBINATION METER ASSEMBLY |
| *5 | DLC3 | *6 | RADIO RECEIVER ASSEMBLY (A/C CONTROL PANEL) |
| *7 | ION GENERATOR SUB-ASSEMBLY (w/ Ion Generator) | *8 | AIR CONDITIONING AMPLIFIER ASSEMBLY |
| *9 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) | *10 | MULTI-DISPLAY ASSEMBLY (for 8 Inch Display) |
| *11 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY - ECU-B NO. 2 FUSE - ECU-IG1 NO. 2 FUSE - ECU-IG1 NO. 3 FUSE - ECU-ACC FUSE (w/o Stop and Start System) |
*12 | AIRBAG SENSOR ASSEMBLY |
| *13 | ENGINE STOP AND START ECU (w/ Stop and Start System) | *14 | METER MIRROR SUB-ASSEMBLY (w/ Headup Display System) |
| *15 | 4WD ECU ASSEMBLY (for AWD) | *16 | DRIVING SUPPORT ECU ASSEMBLY (w/ Pre-crash Safety System) |
| *17 | ACCESSORY METER ASSEMBLY (for 12.3 Inch Display) | - |
ILLUSTRATION
| *A | for LHD | - | - |
| *1 | NO. 1 COOLER THERMISTOR | *2 | QUICK HEATER ASSEMBLY (w/ PTC Heater) |
| *3 | AIR CONDITIONING RADIATOR ASSEMBLY | *4 | BLOWER ASSEMBLY |
| *5 | BLOWER MOTOR WITH FAN SUB-ASSEMBLY | *6 | COOLER EXPANSION VALVE |
| *7 | NO. 1 COOLER EVAPORATOR SUB-ASSEMBLY | *8 | HEATER RADIATOR UNIT SUB-ASSEMBLY |
ILLUSTRATION
| *A | for RHD | - | - |
| *1 | NO. 1 COOLER THERMISTOR | *2 | QUICK HEATER ASSEMBLY (w/ PTC Heater) |
| *3 | AIR CONDITIONING RADIATOR ASSEMBLY | *4 | BLOWER ASSEMBLY |
| *5 | BLOWER MOTOR WITH FAN SUB-ASSEMBLY | *6 | COOLER EXPANSION VALVE |
| *7 | NO. 1 COOLER EVAPORATOR SUB-ASSEMBLY | *8 | HEATER RADIATOR UNIT SUB-ASSEMBLY |
ILLUSTRATION
| *A | for LHD | - | - |
| *1 | NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY | *2 | NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY |
| *3 | NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY | *4 | NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY |
| *5 | AIR CONDITIONING HARNESS ASSEMBLY | - | - |
ILLUSTRATION
| *A | for RHD | - | - |
| *1 | NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY | *2 | NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY |
| *3 | NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY | *4 | NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY |
| *5 | AIR CONDITIONING HARNESS ASSEMBLY | - | - |
