AIR CONDITIONING SYSTEM, Diagnostic DTC:B1497/97

DTC Code DTC Name
B1497/97 BUS IC Communication Malfunction

DESCRIPTION



DTC No. Detection Item DTC Detection Condition Trouble Area Memory
B1497/97 BUS IC Communication Malfunction Error or open in communication line

  • Air conditioning harness assembly

  • No. 1 air conditioning radiator damper servo sub-assembly

  • No. 2 air conditioning radiator damper servo sub-assembly

  • No. 3 air conditioning radiator damper servo sub-assembly

  • No. 1 blower damper servo sub-assembly

  • Air conditioning amplifier assembly

  • No. 2 air conditioning harness assembly*2

  • Rear No. 1 cooling unit damper servo sub-assembly*2

  • Rear No. 2 cooling unit damper servo sub-assembly*2

Memorized

(10 sec. or more)*1

WIRING DIAGRAM


  1. FRONT AIR CONDITIONING SYSTEM

    B005Q3KE02

  2. REAR AIR CONDITIONING SYSTEM (w/ Rear Air Conditioning System)

    B005POWE03

CAUTION / NOTICE / HINT

Note

Inspect the fuses for circuits related to this system before performing the following procedure.

PROCEDURE


  1. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT)


    1. Disconnect the J43 and J48* air conditioning amplifier assembly connector.

    2. Measure the voltage according to the value(s) in the table below.

      Standard Voltage
      Tester Connection Condition Specified Condition
      J43-1 (B) - Body ground Always 11 to 14 V
      J48-4 (+B2) - Body ground* Always 11 to 14 V

      • *: w/ Rear Air Conditioning System

      Result
      Proceed to
      OK
      NG

    NG

    REPAIR OR REPLACE HARNESS OR CONNECTOR

    OK

  2. CONFIRM MODEL


    1. Choose the model to be inspected.

      Result
      Result Proceed to
      for LHD A
      for RHD B

    B

    PERFORM ACTIVE TEST USING GTS Click here

    A

  3. PERFORM ACTIVE TEST USING GTS


    1. Connect the J43 and J48* air conditioning amplifier assembly connector.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Active test.

    6. Perform the Active Test according to the display on the GTS.


      Body Electrical > Air Conditioner > Active Test
      Tester Display Measurement Item Control Range Diagnostic Note
      Air Mix Servo Targ Pulse(D) No. 1 air conditioning radiator damper servo sub-assembly (driver side air mix) pulse

      Min.: 128

      Max.: 383

      		 Operates between 165 to 257 pulses
      Air Mix Servo Targ Pulse(P) No. 1 air conditioning radiator damper servo sub-assembly (front passenger side air mix) pulse

      Min.: 128

      Max.: 383

      		 Operates between 255 to 347 pulses
      Air Outlet Servo Pulse (D) No. 2 air conditioning radiator damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 164 to 256 pulses
      Air Inlet Damper Targ Pulse No. 1 blower damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 220 to 256 pulses
      Rear Air Mix Servo Targ Pulse Rear No. 2 cooling unit damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 254 to 299 pulses*
      Air Outlet Servo Pulse (P) No. 1 air conditioning radiator damper servo sub-assembly (front passenger side mode) pulse

      Min.: 128

      Max.: 383

      		 Operates between 256 to 348 pulses
      A/O Servo Pulse(F&R D) Rear No. 1 cooling unit damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 200 to 275 pulses*
      A/O Servo Pulse(Rr D) No. 3 air conditioning radiator damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 158 to 260 pulses

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Mix Servo Targ Pulse(D)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Mix Servo Targ Pulse(P)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Outlet Servo Pulse (D)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Inlet Damper Targ Pulse

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Rear Air Mix Servo Targ Pulse

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Outlet Servo Pulse (P)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      A/O Servo Pulse(F&R D)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      A/O Servo Pulse(Rr D)

      • *: w/ Rear Air Conditioning System

      OK
      Arm of the damper servo motor selected in the Active Test operates smoothly.

    7. According to the test result, proceed to the next step.

      Result
      Result Proceed to
      All of the damper servo motors are normal A
      One of the damper servo motors is malfunctioning B
      All of the front damper servo motors are malfunctioning C
      All of the rear damper servo motors are malfunctioning D

    A

    REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY Click here

    C

    GO TO STEP 17 Click here

    D

    GO TO STEP 20 Click here

    B

  4. SYSTEM CHECK


    1. According to the test result, proceed to the next step.

      Result
      Result Proceed to
      Only the No. 1 blower damper servo sub-assembly is malfunctioning A
      Only the No. 1 air conditioning radiator damper servo sub-assembly (driver side air mix) is malfunctioning B
      Only the No. 1 air conditioning radiator damper servo sub-assembly (front passenger side air mix) is malfunctioning
      Only the No. 1 air conditioning radiator damper servo sub-assembly (front passenger side mode) is malfunctioning
      Only the No. 2 air conditioning radiator damper servo sub-assembly is malfunctioning C
      Only the No. 3 air conditioning radiator damper servo sub-assembly is malfunctioning D
      Only the rear No. 1 cooling unit damper servo sub-assembly is malfunctioning E
      Only the rear No. 2 cooling unit damper servo sub-assembly is malfunctioning F

    B

    REPLACE NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY Click here

    C

    REPLACE NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY Click here

    D

    REPLACE NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY Click here

    E

    REPLACE REAR NO. 1 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY Click here

    F

    REPLACE REAR NO. 2 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY Click here

    A

  5. REPLACE NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 1 blower damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

  6. REPLACE NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 1 air conditioning radiator damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 17 Click here

  7. REPLACE NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 2 air conditioning radiator damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 17 Click here

  8. REPLACE NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 3 air conditioning radiator damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 17 Click here

  9. REPLACE REAR NO. 1 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY


    1. Replace the rear No. 1 cooling unit damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (REAR NO. 1 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 20 Click here

  10. REPLACE REAR NO. 2 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY


    1. Replace the rear No. 2 cooling unit damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (REAR NO. 2 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 20 Click here

  11. PERFORM ACTIVE TEST USING GTS


    1. Connect the J43 and J48* air conditioning amplifier assembly connector.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Active test.

    6. Perform the Active Test according to the display on the GTS.


      Body Electrical > Air Conditioner > Active Test
      Tester Display Measurement Item Control Range Diagnostic Note
      Air Mix Servo Targ Pulse(D) No. 1 air conditioning radiator damper servo sub-assembly (driver side air mix) pulse

      Min.: 128

      Max.: 383

      		 Operates between 255 to 347 pulses
      Air Mix Servo Targ Pulse(P) No. 1 air conditioning radiator damper servo sub-assembly (front passenger side air mix) pulse

      Min.: 128

      Max.: 383

      		 Operates between 165 to 257 pulses
      Air Outlet Servo Pulse (D) No. 1 air conditioning radiator damper servo sub-assembly (driver side mode) pulse

      Min.: 128

      Max.: 383

      		 Operates between 256 to 348 pulses
      Air Inlet Damper Targ Pulse No. 1 blower damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 220 to 256 pulses
      Rear Air Mix Servo Targ Pulse Rear No. 2 cooling unit damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 254 to 299 pulses*
      Air Outlet Servo Pulse (P) No. 2 air conditioning radiator damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 164 to 278 pulses
      A/O Servo Pulse(F&R D) Rear No. 1 cooling unit damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 200 to 275 pulses*
      A/O Servo Pulse(Rr D) No. 3 air conditioning radiator damper servo sub-assembly pulse

      Min.: 128

      Max.: 383

      		 Operates between 158 to 260 pulses

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Mix Servo Targ Pulse(D)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Mix Servo Targ Pulse(P)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Outlet Servo Pulse (D)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Inlet Damper Targ Pulse

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Rear Air Mix Servo Targ Pulse

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      Air Outlet Servo Pulse (P)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      A/O Servo Pulse(F&R D)

      Body Electrical > Air Conditioner > Active Test
      Tester Display
      A/O Servo Pulse(Rr D)

      • *: w/ Rear Air Conditioning System

      OK
      Arm of the damper servo motor selected in the Active Test operates smoothly.

    7. According to the test result, proceed to the next step.

      Result
      Result Proceed to
      All of the damper servo motors are normal A
      One of the damper servo motors is malfunctioning B
      All of the front damper servo motors are malfunctioning C
      All of the rear damper servo motors are malfunctioning D

    A

    REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY Click here

    C

    GO TO STEP 17 Click here

    D

    GO TO STEP 20 Click here

    B

  12. SYSTEM CHECK


    1. According to the test result, proceed to the next step.

      Result
      Result Proceed to
      Only the No. 1 blower damper servo sub-assembly is malfunctioning A
      Only the No. 1 air conditioning radiator damper servo sub-assembly (driver side air mix) is malfunctioning B
      Only the No. 1 air conditioning radiator damper servo sub-assembly (front passenger side air mix) is malfunctioning
      Only the No. 1 air conditioning radiator damper servo sub-assembly (driver side mode) is malfunctioning
      Only the No. 2 air conditioning radiator damper servo sub-assembly is malfunctioning C
      Only the No. 3 air conditioning radiator damper servo sub-assembly is malfunctioning D
      Only the rear No. 1 cooling unit damper servo sub-assembly is malfunctioning E
      Only the rear No. 2 cooling unit damper servo sub-assembly is malfunctioning F

    B

    REPLACE NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY Click here

    C

    REPLACE NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY Click here

    D

    REPLACE NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY Click here

    E

    REPLACE REAR NO. 1 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY Click here

    F

    REPLACE REAR NO. 2 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY Click here

    A

  13. REPLACE NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 1 blower damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 1 BLOWER DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

  14. REPLACE NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 1 air conditioning radiator damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 1 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 17 Click here

  15. REPLACE NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 2 air conditioning radiator damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 2 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 17 Click here

  16. REPLACE NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY


    1. Replace the No. 3 air conditioning radiator damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 3 AIR CONDITIONING RADIATOR DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

  17. REPLACE AIR CONDITIONING HARNESS ASSEMBLY


    1. Replace the air conditioning harness assembly.

      Click here

      Tech Tips

      Since the air conditioning harness assembly cannot be inspected while it is removed from the vehicle, replace the air conditioning harness assembly with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (AIR CONDITIONING HARNESS ASSEMBLY WAS DEFECTIVE)

    B

    REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY Click here

  18. REPLACE REAR NO. 1 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY


    1. Replace the rear No. 1 cooling unit damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (REAR NO. 1 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

    GO TO STEP 20 Click here

  19. REPLACE REAR NO. 2 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY


    1. Replace the rear No. 2 cooling unit damper servo sub-assembly.

      Click here

      Tech Tips

      Since the servo motor cannot be inspected while it is removed from the vehicle, replace the servo motor with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (REAR NO. 2 COOLING UNIT DAMPER SERVO SUB-ASSEMBLY WAS DEFECTIVE)

    B

  20. REPLACE NO. 2 AIR CONDITIONING HARNESS ASSEMBLY


    1. Replace the air conditioning harness assembly.

      Click here

      Tech Tips

      Since the air conditioning harness assembly cannot be inspected while it is removed from the vehicle, replace the air conditioning harness assembly with a new or known good one and check that the condition returns to normal.

    2. Connect the GTS to the DLC3.

    3. Turn the engine switch on (IG).

    4. Turn the GTS on.

    5. Enter the following menus: Body Electrical / Air Conditioner / Trouble Codes.

    6. Check for DTCs.


      Body Electrical > Air Conditioner > Trouble Codes
      Result
      Result Proceed to
      DTC B1497/97 is not output A
      DTC B1497/97 is output B

    A

    END (NO. 2 AIR CONDITIONING HARNESS ASSEMBLY WAS DEFECTIVE)

    B

    REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY Click here
