REAR NO. 2 SEAT OUTER BELT ASSEMBLY INSPECTION

PROCEDURE


  1. INSPECT REAR NO. 2 SEAT OUTER BELT ASSEMBLY RH


    1. B005P5YC01
      *a Retractor
      *b Standard Position
      *c 15°
      *d Unlock
      *e Lock

      Before installing the rear No. 2 seat outer belt assembly RH, check the ELR function.

      Note

      Do not disassemble the retractor.


      1. Hold the retractor at the angle it would be positioned when it is installed to the vehicle (standard position). Check that the seatbelt can be pulled from the retractor when the angle of the retractor is between 15° forward and 15° rearward of the standard position.

        Hold the retractor at the angle it would be positioned when it is installed to the vehicle (standard position). Check that the seatbelt locks when the angle of the retractor is 15° or more forward or 15° or more rearward of the standard position.

        If the result is not as specified, replace the rear No. 2 seat outer belt assembly RH.

  2. INSPECT REAR NO. 2 SEAT OUTER BELT ASSEMBLY LH


    1. B005NY6C01
      *a Retractor
      *b Standard Position
      *c 15°
      *d Unlock
      *e Lock

      Before installing the rear No. 2 seat outer belt assembly LH, check the ELR function.

      Note

      Do not disassemble the retractor.


      1. Hold the retractor at the angle it would be positioned when it is installed to the vehicle (standard position). Check that the seatbelt can be pulled from the retractor when the angle of the retractor is between 15° forward and 15° rearward of the standard position.

        Hold the retractor at the angle it would be positioned when it is installed to the vehicle (standard position). Check that the seatbelt locks when the angle of the retractor is 15° or more forward or 15° or more rearward of the standard position.

        If the result is not as specified, replace the rear No. 2 seat outer belt assembly LH.
