INTAKE MANIFOLD COMPONENTS

ILLUSTRATION

A01LC5FC01
*1 FRONT FENDER SEAL LH *2 INTAKE MANIFOLD
*3 PURGE VSV *4 NO. 1 FUEL HOSE
*5 NO. 2 WATER BY-PASS HOSE *6 PURGE LINE HOSE
*7 NO. 3 PCV HOSE *8 UNION TO CONNECTOR TUBE HOSE
*9 HEATER WATER PIPE SUB-ASSEMBLY *10 INTAKE MANIFOLD INSULATOR
*11 NO. 2 INTAE MANIFOLD INSULATOR *12 GASKET
*13 WIRE HARNESS *14 WIRE HARNESS CLAMP BRACKET
B0068CQ N*m (kgf*cm, ft.*lbf): Specified torque ‚óŹ Non-reusable part
