OUTER REAR VIEW MIRROR REMOVAL

CAUTION / NOTICE / HINT

Tech Tips


  • Use the same procedure for RHD and LHD vehicles.

  • The procedure listed below is for LHD vehicles.

  • Use the same procedure for the RH and LH sides.

  • The procedure listed below is for the LH side.

PROCEDURE


  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH

    Click here

  2. REMOVE FRONT ARMREST ASSEMBLY LH (w/ Power Mirror Control System)

    Click here

  3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL (w/ Power Mirror Control System, for Driver Side)

    Click here

  4. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL (w/ Power Mirror Control System, for Front Passenger Side)

    Click here

  5. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG LH (w/ Power Mirror Control System)

    Click here

  6. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (w/ Power Mirror Control System)

    Click here

  7. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY LH


    1. w/o Power Mirror Control System:


      1. B0028SH

        Remove the 3 bolts.

      2. B0026JFC01
        B0069FO Remove in this Direction

        Detach the claw and remove the outer rear view mirror assembly LH.

    2. w/ Power Mirror Control System:


      1. B0025XBC01
        B0068HS Connector
        B006964 Bolt

        Disconnect the connector.

      2. Remove the 3 bolts.

      3. B0028EIC01
        B0069FO Remove in this Direction

        Detach the claw and remove the outer rear view mirror assembly LH.
