SEAT HEATER SYSTEM

Info Added 2017-04-18


  1. OUTLINE


    1. A seat heater system is available for the front seats depending on the specification.

    2. The seat heater function can be turned on (HI/MID/LO) or off using the seat heater switch located in the air conditioning control assembly.

    3. Each seat heater switch has built-in indicator lights. An indicator light (LO, MID or HI) will illuminate in yellow to indicate that the heating function is operating.

    4. Both zone A and zone B operate with zone A operating at a higher temperature than zone B for comfort.

      A001MZSC01
      B003XHG Zone A B003XGX Zone B

    5. Thermostats that are enclosed in the cushions control the output temperature of the seat heater.
