COOLING SYSTEM


  1. CONSTRUCTION


    1. For enhanced corrosion resistance, the engine water pump assembly uses a stainless steel rotor.

      A018G91C04
      *1 Engine Water Pump Assembly *2 Water Inlet Housing
      *3 Bearing *4 Stainless Steel Rotor
      *5 Water Pump Pulley - -
      *a Water Pump Cross Section - -
