MULTI-TERRAIN MONITOR SYSTEM


  1. PRECAUTION


    1. In the following cases, it may become difficult to see items in the image on the screen, but this does not indicate a malfunction:


      • In the dark (for example, at night)

      • When the temperature near the lens is very high or low

      • When water droplets are present on the television camera, or when humidity is high (for example, when it rains)

      • When foreign matter (for example, mud or salt) is present on the television camera lens

      • When sunlight or headlights are shining directly into the television camera lens

      • When the camera lens is damaged by flying stones

    2. When washing the vehicle with a high-pressure washer, do not spray water on the rear television camera assembly surrounding area. High-pressure water can damage the camera.

    3. If a bright light (for example, sunlight reflected off the vehicle body) is picked up by the camera, the smear effect* (particular to the CCD camera) may occur.

      A01W683C01
      *1 Vertical Streak *2 Bright Light

    Tech Tips

    *: Smear effect

    A phenomenon that occurs when a bright light (for example, sunlight reflected off the vehicle body) is received by the camera and transmitted to the screen. The light source will appear to have a vertical streak above and below it.
