BODY STRUCTURE

OUTLINE

1. Light Weight and Highly Rigid Body




   1. High-strength sheet steel and ultra high-strength sheet steel are used in order to achieve excellent body rigidity and a lightweight body.

2. Safety Features




   1. The impact absorbing structure minimizes cabin deformation by effectively helping to absorb the impact energy in the event of a front, side or rear collision. This provides high-performance occupant protection.

3. Rust-resistant Body




   1. Rust-resistant performance is enhanced by the extensive use of anti-corrosion sheet steel, as well as by an anti-corrosion treatment that includes the application of anti-rust wax, sealer and anti-chipping paint to the easily corroded parts such as the hood and fender.

4. Low Vibration and Low Noise Body




   1. Effective application of vibration damping and noise suppressant materials reduces engine, wind and road noise.

5. Aerodynamics




   1. Various types of airflow routing parts that control airflow are provided under the floor, and an undercover is provided to make the under-floor area flat in order to ensure excellent aerodynamic performance.

6. Parts with Low Repair Cost




   1. In minor collisions in which no damage is inflicted to the bumper reinforcement, repair cost is lowered by minimizing the number of parts that require replacement in order to be reused.

MAIN FEATURES
