CAN COMMUNICATION SYSTEM
| *1 | Sensor Bus |
| *2 | Driving Support ECU Assembly |
| *3 | Millimeter Wave Radar Sensor Assembly |
| *4 | No. 3 Junction Connector |
| *1 | Local Bus |
| *2 | Blind Spot Monitor Sensor Assembly RH |
| *3 | Blind Spot Monitor Sensor Assembly LH |
| *1 | Power Management Bus |
| *2 | Power Management Control ECU |
| *3 | No. 1 Junction Connector |
| *4 | Air Conditioning Amplifier Assembly |
