VACUUM RESERVOIR(for 5L-E) INSPECTION

PROCEDURE


  1. INSPECT VACUUM RESERVOIR VACUUM CHECK VALVE ASSEMBLY


    1. B003O5GC01
      *a Hose Side
      *b Pump Side

      Check that air flows from the hose side to the pump side.

    2. Check that air does not flow from the pump side to the hose side.

      If necessary, replace the check valve sub-assembly.
