AUTOMATIC HIGH BEAM SYSTEM, Diagnostic DTC:B124C

DTC Code DTC Name
B124C Automatic High Beam Camera

DESCRIPTION

This DTC is stored when the main body ECU (multiplex network body ECU) detects a malfunction in the forward recognition camera.

DTC No. Detection Item DTC Detection Condition Trouble Area
B124C Automatic High Beam Camera Malfunction in forward recognition camera Forward recognition camera system

WIRING DIAGRAM

B003YCTE66
*1 Forward Recognition Camera
*2 Main Body ECU (Multiplex Network Body ECU)
*3 CAN Communication Line

PROCEDURE


  1. CHECK FORWARD RECOGNITION CAMERA SYSTEM


    1. Check the forward recognition camera system.

      Click here

      Result
      Proceed to
      NEXT

    NEXT

    END
