REAR CENTER SEAT OUTER BELT ASSEMBLY COMPONENTS
ILLUSTRATION
| *1 | REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH | *2 | ROOF HEADLINING ASSEMBLY |
| *3 | SHOULDER BELT ANCHOR COVER RH | - | - |
 |
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
ILLUSTRATION
| *1 | REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH | *2 | ROOF HEADLINING ASSEMBLY |
| *3 | SHOULDER BELT ANCHOR COVER RH | - | - |
| |
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
