THEFT DETERRENT SYSTEM(w/o Entry and Start System) PARTS LOCATION
ILLUSTRATION
ILLUSTRATION
ILLUSTRATION
ILLUSTRATION
| *1 | UNLOCK WARNING SWITCH ASSEMBLY |
| *2 | CLOCK ASSEMBLY |
| *3 | - SECURITY INDICATOR LIGHT |
| *4 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) |
ILLUSTRATION
| *1 | UNLOCK WARNING SWITCH ASSEMBLY |
| *2 | CLOCK ASSEMBLY |
| *3 | - SECURITY INDICATOR LIGHT |
| *4 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) |
