THEFT DETERRENT SYSTEM(w/o Entry and Start System) PARTS LOCATION

ILLUSTRATION

ILLUSTRATION

ILLUSTRATION

ILLUSTRATION

for LHD

*1	UNLOCK WARNING SWITCH ASSEMBLY
*2	CLOCK ASSEMBLY
*3	- SECURITY INDICATOR LIGHT
*4	MAIN BODY ECU (COWL SIDE JUNCTION BLOCK ASSEMBLY LH)

ILLUSTRATION

for RHD

*1	UNLOCK WARNING SWITCH ASSEMBLY
*2	CLOCK ASSEMBLY
*3	- SECURITY INDICATOR LIGHT
*4	MAIN BODY ECU (COWL SIDE JUNCTION BLOCK ASSEMBLY LH)
