FRONT AIRBAG SENSOR COMPONENTS
ILLUSTRATION
ILLUSTRATION
| *A | for Halogen Headlight | *B | for LED Headlight |
| *1 | FRONT AIRBAG SENSOR | *2 | FRONT FENDER SIDE PANEL PROTECTOR |
| *3 | HEADLIGHT ASSEMBLY | - | - |
 |
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
