LIN COMMUNICATION SYSTEM
SYSTEM DIAGRAM
LIN Communication between Components Related to Air Conditioning
*1
Air Conditioning Amplifier
*2
Air Conditioning Control
*3
LIN Communication Line
LIN Communication between Components Related to Rain Sensor (w/ Rain Sensor)
*1
Windshield Wiper Relay Assembly
*2
Rain Sensor
*3
LIN Communication Line
